Cutting Edge Cross Section11 Type17 Type M ClassE ClassM ClassE Class Coated CarbideCermetCoated CarbideCoated CarbideCoated CarbideCarbide Cutting Edge Sharpness High-speedCast IronNon-ferrousMetalChamferingGroove /T-SlotR / 3DProfilingRadiusMulti-PurposeHigh FeedShoulderMillingFace MillingMillingCutters SEC-WaveMill WEZ Type ■ Grade Application Range ■ Grade Features Newly developed general-purpose ACU2500 New AbsotechTM (absolute technology) coating technology grade suitable for various work materials has now been released. that realises absolute stability Enhanced lineup of coatings, cemented carbide and cermet for milling steel, stainless CVD steel, cast iron, and aluminum alloy Work Material Finishing to Light Cutting Medium Cutting Rough to Heavy Cutting Special Surface Treatment Suppresses thermal cracking by introducing high ACP2000 C Al2O3 compressive stress, resulting in chipping resistance more than twice as good as conventional types P ACU2500 Crystal Orientation Control Al2O3 Steel P ACP3000T2500A TiCN By controlling the growth direction, Al2O3 isreinforced for crater wear resistance morethan twice as good as conventional typesH P ACU2500 High Hardness TiCNIncreased TiCN hardness by using a C-rich Stainless Steel ACM200 C composition for flank wear resistance more P ACM300 Carbide than twice as good as conventional types ACK2000 C substrate Applicable Grades: ACP2000, ACK2000 P ACK3000 PVD Cast Iron P ACU2500 New Super Multi-Layered Composition Higher hardness and twice the P DL2000 conventional wear resistance due to a fine crystal structure Non-Ferrous Metal AlTiCrBN-based nano-layered H20 Film coating 5nm The letters "C" and "P" at the end of each grade indicate the coating type. C : CVD P : PVD Cross Section ofCutting Edge CoatingHigh Adhesion Strength TEM Image Significantly improved coating adhesion Chipping resistance more than twice as good as conventional types Carbide Applicable Grades: ACU2500, ACP3000, ACK3000 substrate ■ Chipbreaker Lineup Work Material Steel, stainless steel, cast iron, heat-resistant alloy, titanium alloy, hardened steel Non-ferrous Metal S L Type G Type H Type F Type P Type S Type Chipbreaker F,P L G 11 Type Not Available 28° 20° 28° 28° 28° H 17 Type 28° 20° 10° 28° 28° 28° Applications Light CuttingLow-rigidity MillingMain ChipbreakersGeneral-purpose toInterrupted MillingHeavy CuttingHeavy interrupted machiningHardened SteelLight CuttingLight CuttingMedium FinishingHigh-precision MachiningFor Non-Ferrous MetalsLow-burr designHigh wall surface squarenessCutting Edge Strength ■ Product Range (Insert) Nose Radius (mm) Type R0.2 R0.4 R0.8 R1.2 R1.6 R2.0 R2.4 R3.0 R3.2 R4.0 R5.0 R6.4 AOMT 11T3○○PEER-G ○ ● ● ○ ○ ○ ○ ○ ○ AOMT 11T3○○PEER-H ● ● ○ ○ AOET 11T3○○PEER-F ○ ● ● ○ AOET 11T3○○PEER-P16 ○ ● ● ○ AOET 11T3○○PEER-P20 ○ ● ● ○ AOET 11T3○○PEER-P25 ○ ● ● ○ AOET 11T3○○PEFR-S ○ ● ● ○ AOMT 1705○○PEER-L ○ ● ● ○ ○ AOMT 1705○○PEER-G ○ ● ● ○ ○ ○ ○ ○ ○ ○ ○ ○ AOMT 1705○○PEER-H ● ● ○ ○ AOET 1705○○PEER-F ○ ● ● ○ ○ AOET 1705○○PEER-P25 ○ ● ● ○ AOET 1705○○PEER-P32 ○ ● ● ○ AOET 1705○○PEFR-S ○ ● ● ○ ●: Standard stock ○: Planned stock H53
