CartridgesToolingTooling IGETALLOY ABS System Head Adapter Clamp Screw Slide Pin Position Pin G For indexable cutters... Taper ScrewCap Screw For boring quills... For drills... For toolposts... ■ ABS Standard (Adapter) ● Adapter Dimensions Dimensions (mm) ● Spare Parts Clamp Screw Cat. No. Body Dia. Shank Dia. Shank Length Min.ClampingLengthBDDCBCBDPLBSet Cat. No. Clamp Screw Taper Screw ABS 25W  25  13  22 13.0 ABS 25-FS-W ABS 25-F1 ABS 25-F2 ABS 32W  32  16  25 16.0 ABS 32-FS-W ABS 32-F1 ABS 32-F2 ABS 40W  40  20  30 18.5 ABS 40-FS-W ABS 40-F1 ABS 40-F2 ABS 50W  50  28  34 22.0 ABS 50-FS-W ABS 50-F1 ABS 50-F2 ABS 63W  63  34  41 28.0 ABS 63-FS-W ABS 63-F1 ABS 63-F2 ABS 80W  80  46  48 34.0 ABS 80-FS-W ABS 80-F1 ABS 80-F2 ABS100W 100  56  58 40.5 ABS100-FS-W ABS100-F1 ABS100-F2 Taper Screw LB (Minimum) ABS125W 125  70  76 51.0 ABS125-FS-W ABS125-F1 ABS125-F2 CBDP ABS160W 160  90  96 53.0 ABS160-FS-W ABS160-F1 ABS160-F2 ABS200W 200 112 116 82.0 ABS200-FS-W ABS200-F1 ABS200-F2 G23 BD DCB
