ToolingToolingCartridges SEC-Micro Units This section introduces an overview of the series. Note: Use MUP type micro units when designing new tooling. Refer to the separate "SEC-Cartridge Unit / Micro Unit" catalog for details on Micro Units Conventional tool types (MUN type) are manufactured only as (holders, inserts, spare parts) and quill unit seat machining. replacement parts. ■ Micro Unit Cat. No. by Model / Tooling Type MUP Type MUN Type G Min. Min. Illustrations Tooling Cat. No. Bore Dia. Stock Cat. No. Bore Dia. Stock (mm) (mm) MUP1-A0 25 D MUN2 -A0 36 MUP2-A0 36 D MUN3 -A0 47 MUP3-A0 47 D MUN3L-A0 54 MUP4-A0 73 MUN4 -A0 73 MUN4L-A0 78 MUP1-A15 25 MUN2 -A15 36 MUP2-A15 36 MUN3 -A15 47 MUP3-A15 47 MUN3L-A15 54 MUP4-A15 73 MUN4 -A15 73 MUN4L-A15 78 MUP1-V0 25 D MUN2 -V0 36 MUP2-V0 36 D MUN3 -V0 47 MUP3-V0 47 D MUN3L-V0 54 MUP4-V0 73 MUN4 -V0 73 MUN4L-V0 78 MUP1-V15 25 MUN2 -V15 36 MUP2-V15 36 MUN3 -V15 47 MUP3-V15 47 MUN3L-V15 54 MUP4-V15 73 MUN4 -V15 73 MUN4L-V15 78 *If a left hand unit is required, include "LH" after the catalogue number. (Ex.: MUP1-A0-LH, MUP1-V0-LH) *Inserts and wrenches are not included with Micro Units. G24
