ToolingToolingCartridges 55° WFWF ø63ø63ø63 HSK Tooling Systems General External Turning and Profiling Double Clamp DDJN Fig 1 External Turning and Profiling 93° 55° LF Insert (Representative example) Applicable Insert Cat. No. Ref. Page G DN□□1504○○ B32onFigure shows right hand (R) tool.DNMG150408N-GE Holder  Parts Dimensions (mm) Stock Overhang Cutting Edge Clamp Set Shim ShimScrew ShimWrenchWrench Cat. No. Previous Cat. No. Fig R L LF WF Nm HSK63TH-DDJN R/L-DX15 H63A-WH-DDJN R/L-DX15 65 45 1 SCP-2 5.0 DNS1504 BFTX0409N TRX15(*) LH040 *Wrench for shim is sold separately from the main unit. Clamp Set Parts C44 General External Turning and Profiling Double Clamp DDNN Fig 1 External Turning and Profiling 62°30' Insert (Representative example) LF Applicable Insert Cat. No. Ref. Page DN□□1504○○ B32on DNMG150408N-GE Holder  Parts Dimensions (mm) Overhang Clamp Set Shim ShimScrew ShimWrenchWrench Cat. No. Previous Cat. No. Stock Fig LF Nm HSK63TH-DDNN N-H15 H63A-WH-DDNN N-H15HSK63TH-DDNN N-L15H63A-WH-DDNN N-L1510014011SCP-2 5.0 DNS1504 BFTX0409N TRX15(*) LH040 *Wrench for shim is sold separately from the main unit. Clamp Set Parts C44 General External Turning and Profiling Double Clamp DVPN Fig 1 Undercutting 117°30'35°LF Insert (Representative example)Applicable Insert Cat. No. Ref. Page VN□□1604○○ B66on VNMG 160408N-GE Figure shows right hand (R) tool. Holder  Parts Dimensions (mm) Stock Overhang Cutting Edge Clamp Set Shim ShimScrew ShimWrenchWrench Cat. No. Previous Cat. No. Fig R L LF WF Nm HSK63TH-DVPN R/L-DX16 H63A-WH-DVPN R/L-DX16 65 45 1 SCP-4 5.0 VNS1604 BFTX0307N TRX10(*) LH040 *Wrench for shim is sold separately from the main unit. Clamp Set Parts C44 G4 N m Recommended Tightening Torque (N·m)
