FRACTIONAL & METRIC Hi-PerCarb® 32° 145° 2 OAL TOLERANCES (inch) LCF LS LU ≤.1181 DIAMETER DC = +.00008/+.00047 DCON = h 6 DC DCON 135 3xD >.1181–.2362 DIAMETER FRACTIONAL & METRIC SERIES DC = +.00016/+.00063 inch & mm EDP NO. • Double margin design DCON = h 6 CUTTING DECIMAL METRIC TAP SIZE SHANK OVERALL FLUTE CLEARED SHANK Ti-NAMITE-A DIAMETER EQUIV. EQUIV. REFERENCE DIAMETER LENGTH LENGTH LENGTH LENGTH (AlTiN) improves accuracy and >.2362–.3937 DIAMETER DC ONLY DCON OAL LCF LU LS surface finish along with increased strength DC = +.00024/+.00083 1/64 0.0156 0.40 1/8 1-1/2 1/8 5/64 1 51752* for aggressive drilling DCON = h 6 1/32 0.0312 0.79 1/8 1-1/2 1/4 3/16 1 51269* • Specialized self- 3/64 0.0469 1.19 1/16-64 1/8 1-1/2 3/8 5/16 1 51270* centering notched point >.3937–.7087 DIAMETER 1,25 mm 0.0492 3,0 38,0 9,5 8,0 25,0 64500* eliminates the need for DC = +.00028/+.00098 spot drilling decreasing 1,45 mm 0.0571 3,0 38,0 9,5 8,0 25,0 64501* DCON = h 6 thrust and deflection #53 0.0595 1.51 1/8 1-1/2 3/8 5/16 1 64502* >.7087–1.1811 DIAMETER 1/16 0.0625 1.59 5/64-60 1/8 2 7/16 3/8 1-1/4 51271* • Engineered edge protection improves DC = +.00031/+.00114 1,6 mm 0.0630 3,0 50,0 11,0 9,0 32,0 64503* edge strength and DCON = h 6 1,75 mm 0.0689 3,0 50,0 11,0 9,0 32,0 64504* reduces edge fatigue #50 0.0700 1.78 1/8 2 7/16 3/8 1-1/4 64505* allowing for increased TOLERANCES (mm) feed rates 5/64 0.0781 1.98 1/8 2 1/2 7/16 1-1/4 51272* #47 0.0785 1.99 1/8 2 1/2 7/16 1-1/4 64506* • Recommended for ≤3 DIAMETER materials ≤ 56 HRc DC = +0,002/+0,012 2,05 mm 0.0807 3,0 50,0 12,0 11,0 32,0 64507* (≤ 577 Bhn) DCON = h 6 #46 0.0810 2.06 1/8 2 1/2 7/16 1-1/4 64508* #43 0.0890 2.26 1/8 2 1/2 7/16 1-1/4 64509* >3–6 DIAMETER #42 0.0935 2.37 1/8 2 1/2 7/16 1-1/4 64510* DC = +0,004/+0,016 3/32 0.0938 2.38 1/8-32 1/8 2 1/2 7/16 1-1/4 51273 DCON = h 6 #40 0.0980 2.49 1/8 2 9/16 1/2 1-1/4 51274 2,5 mm 0.0984 3,0 50,0 14,0 12,0 32,0 64511 >6–10 DIAMETER #39 0.0995 2.53 1/8 2 9/16 1/2 1-1/4 51753 DC = +0,006/+0,021 #38 0.1015 2.58 5-40 1/8 2 9/16 1/2 1-1/4 51754 DCON = h 6 #37 0.1040 2.64 5-44 1/8 2 9/16 1/2 1-1/4 51755 >10–18 DIAMETER #36 0.1065 2.71 6-32 1/8 2 9/16 1/2 1-1/4 51756 DC = +0,007/+0,025 7/64 0.1094 2.78 1/8 2 5/8 9/16 1-1/4 51275 DCON = h 6 #35 0.1100 2.79 1/8 2 5/8 9/16 1-1/4 51276 #34 0.1110 2.82 1/8 2 5/8 9/16 1-1/4 51277 >18–30 DIAMETER #33 0.1130 2.87 6-40 1/8 2 5/8 9/16 1-1/4 51757 DC = +0,008/+0,029 2,9 mm 0.1142 3,0 50,0 16,0 14,0 32,0 64512 DCON = h 6 #32 0.1160 2.95 1/8 2 5/8 9/16 1-1/4 51758 3,0 mm 0.1181 6,0 62,0 20,0 17,0 36,0 63155 #31 0.1200 3.05 1/8 2 5/8 9/16 1-1/4 51759 STEELS 3,1 mm 0.1220 6,0 62,0 20,0 17,0 36,0 63741 STAINLESS STEELS 1/8 0.1250 3.18 1/4 2-1/2 3/4 21/32 1-7/16 51330 3,2 mm 0.1260 M3,5 X 0,35 6,0 62,0 20,0 17,0 36,0 63156 CAST IRON #30 0.1285 3.26 1/4 2-1/2 3/4 21/32 1-7/16 51278 3,3 mm 0.1299 M4 X 0,7 6,0 62,0 20,0 17,0 36,0 63157 HIGH TEMP ALLOYS 3,4 mm 0.1339 6,0 62,0 20,0 17,0 36,0 63158 TITANIUM #29 0.1360 3.45 8-32,8-36 1/4 2-1/2 3/4 21/32 1-7/16 51331 3,5 mm 0.1378 M4 X 0,5 6,0 62,0 20,0 17,0 36,0 63159 NON-FERROUS #28 0.1405 3.57 8-40 1/4 2-1/2 3/4 21/32 1-7/16 51760 HARDENED STEELS 9/64 0.1406 3.57 1/4 2-1/2 3/4 21/32 1-7/16 51332 3,6 mm 0.1417 M4 X 0,35 6,0 62,0 20,0 17,0 36,0 63160 #27 0.1440 3.66 1/4 2-1/2 3/4 21/32 1-7/16 51761 For patent 3,7 mm 0.1457 M4.5 X 0,75 6,0 62,0 20,0 17,0 36,0 63161 information visit #26 0.1470 3.73 3/16-24 1/4 2-1/2 3/4 21/32 1-7/16 51762 www.ksptpatents.com #25 0.1495 3.80 10-24 1/4 2-5/8 7/8 23/32 1-7/16 51333 *Single Margin continued on next page 231 DRILLS www.kyocera-sgstool.com DRILLS
