FRACTIONAL & METRIC 3 Flute Drills • Metric: DIN 6539 3 (mm) (inch) 103 TOLERANCES (inch) FRACTIONAL & METRIC SERIES D1 = +.0000/–.0005 D2 = h6 EDP NO. CUTTING DECIMAL METRIC OVERALL FLUTE CLEARED UNCOATED Ti-NAMITE-A TOLERANCES (mm) DIAMETER EQUIV. EQUIV. LENGTH LENGTH LENGTH (AlTiN) D1 = +0,0000/–0,0127 D1 / D2 L1 L2 L3 D2 = h6 #36 0.1065 2.71 2-1/4 1-1/4 1 53036 58011 7/64 0.1094 2.78 2-1/4 1-1/4 1 53107 58012 #35 0.1100 2.79 2-1/4 1-1/4 1 53035 58013 STEELS #34 0.1110 2.82 2-1/4 1-1/4 1 53034 58014 CAST IRON #33 0.1130 2.87 2-1/4 1-1/4 1 53033 58015 #32 0.1160 2.95 2-1/4 1-1/4 1 53032 58016 HARDENED STEELS 3,0 mm 0.1181 46,0 16,0 12,0 63000 68965 NON-FERROUS #31 0.1200 3.05 2-1/4 1-1/4 1 53031 58017 3,1 mm 0.1220 49,0 18,0 14,0 63044 68966 For patent 1/8 0.1250 3.18 2-1/4 1-1/4 1 53108 58018 information visit 3,2 mm 0.1260 49,0 18,0 14,0 63045 68967 www.ksptpatents.com #30 0.1285 3.26 2-1/4 1-1/4 1 53030 58019 3,3 mm 0.1299 49,0 18,0 14,0 63001 68968 3,4 mm 0.1339 52,0 20,0 15,0 63046 68969 #29 0.1360 3.45 2-1/2 1-3/8 1-7/64 53029 58020 3,5 mm 0.1378 52,0 20,0 15,0 63002 68970 #28 0.1405 3.57 2-1/2 1-3/8 1-7/64 53028 58021 9/64 0.1406 3.57 2-1/2 1-3/8 1-7/64 53109 58022 3,6 mm 0.1417 52,0 20,0 15,0 63047 68971 #27 0.1440 3.66 2-1/2 1-3/8 1-7/64 53027 58023 3,7 mm 0.1457 52,0 20,0 15,0 63003 68972 #26 0.1470 3.73 2-1/2 1-3/8 1-7/64 53026 58024 #25 0.1495 3.80 2-1/2 1-3/8 1-7/64 53025 58025 3,8 mm 0.1496 55,0 22,0 17,0 63048 68973 #24 0.1520 3.86 2-1/2 1-3/8 1-7/64 53024 58026 3,9 mm 0.1535 55,0 22,0 17,0 63049 68974 #23 0.1540 3.91 2-1/2 1-3/8 1-7/64 53023 58027 5/32 0.1562 3.97 2-1/2 1-3/8 1-7/64 53110 58028 #22 0.1570 3.99 2-1/2 1-3/8 1-7/64 53022 58029 4,0 mm 0.1575 55,0 22,0 17,0 63004 68975 #21 0.1590 4.04 2-1/2 1-3/8 1-7/64 53021 58030 #20 0.1610 4.09 2-1/2 1-3/8 1-7/64 53020 58031 4,1 mm 0.1614 55,0 22,0 17,0 63050 68976 4,2 mm 0.1654 55,0 22,0 17,0 63005 68977 #19 0.1660 4.22 2-3/4 1-5/8 1-19/64 53019 58032 4,3 mm 0.1693 58,0 24,0 18,0 63051 68978 #18 0.1695 4.31 2-3/4 1-5/8 1-19/64 53018 58033 11/64 0.1719 4.37 2-3/4 1-5/8 1-19/64 53111 58034 #17 0.1730 4.39 2-3/4 1-5/8 1-19/64 53017 58035 4,4 mm 0.1732 58,0 24,0 18,0 63052 68979 continued on next page 304 DRILLS www.kDyRoIcLeLrSa-sgstool.com
