FRACTIONAL & METRIC Straight Flute Drills • Metric: DIN 6539 2 106 TOLERANCES (inch) FRACTIONAL & METRIC SERIES D1 = +.0000/–.0005 D2 = h6 EDP NO. CUTTING DECIMAL METRIC OVERALL FLUTE CLEARED UNCOATED Ti-NAMITE-A TOLERANCES (mm) DIAMETER EQUIV. EQUIV. LENGTH LENGTH LENGTH (AlTiN) D1 = +0,0000/–0,0127 D1 / D2 L1 L2 L3 D2 = h6 1,0 mm 0.0394 26,0 6,0 4,5 66001 66002 #60 0.0400 1.02 1-1/2 1/2 13/32 56060 56269 #59 0.0410 1.04 1-1/2 1/2 13/32 56059 56268 STEELS #58 0.0420 1.07 1-1/2 1/2 13/32 56058 56267 CAST IRON #57 0.0430 1.09 1-1/2 1/2 13/32 56057 56266 HARDENED STEELS #56 0.0465 1.18 1-1/2 1/2 13/32 56056 56265 3/64 0.0469 1.19 1-1/2 1/2 13/32 56103 56135 For patent #55 0.0520 1.32 1-1/2 1/2 13/32 56055 56264 information visit #54 0.0550 1.40 1-1/2 1/2 13/32 56054 56263 www.ksptpatents.com 1,5 mm 0.0591 32,0 9,0 7,0 66003 66004 #53 0.0595 1.51 1-1/2 1/2 13/32 56053 56262 1/16 0.0625 1.59 1-1/2 5/8 1/2 56104 56136 #52 0.0635 1.61 1-11/16 11/16 35/64 56052 56261 #51 0.0670 1.70 1-11/16 11/16 35/64 56051 56260 #50 0.0700 1.78 1-11/16 11/16 35/64 56050 56259 #49 0.0730 1.85 1-11/16 11/16 35/64 56049 56258 #48 0.0760 1.93 1-11/16 11/16 35/64 56048 56257 5/64 0.0781 1.98 1-11/16 11/16 35/64 56105 56137 #47 0.0785 1.99 1-3/4 3/4 39/64 56047 56256 2,0 mm 0.0787 38,0 12,0 9,0 66005 66006 #46 0.0810 2.06 1-3/4 3/4 39/64 56046 56255 #45 0.0820 2.08 1-3/4 3/4 39/64 56045 56254 #44 0.0860 2.18 1-3/4 3/4 39/64 56044 56253 #43 0.0890 2.26 1-3/4 3/4 39/64 56043 56252 #42 0.0935 2.37 1-3/4 3/4 39/64 56042 56251 3/32 0.0938 2.38 1-3/4 3/4 39/64 56106 56138 #41 0.0960 2.44 1-13/16 13/16 21/32 56041 56250 #40 0.0980 2.49 1-13/16 13/16 21/32 56040 56249 2,5 mm 0.0984 43,0 14,0 11,0 66007 66008 #39 0.0995 2.53 1-13/16 13/16 21/32 56039 56248 #38 0.1015 2.58 1-13/16 13/16 21/32 56038 56247 #37 0.1040 2.64 1-13/16 13/16 21/32 56037 56246 #36 0.1065 2.71 1-13/16 13/16 21/32 56036 56245 7/64 0.1094 2.78 1-13/16 13/16 21/32 56107 56139 #35 0.1100 2.79 1-7/8 7/8 45/64 56035 56244 #34 0.1110 2.82 1-7/8 7/8 45/64 56034 56243 continued on next page 300 DRILLS www.kDyRoIcLeLrSa-sgstool.com
