FRACTIONAL & METRIC 2 Flute Drills • Metric: DIN 338 2 101 TOLERANCES (inch) FRACTIONAL & METRIC SERIES D1 = +.0000/–.0005 EDP NO. TOLERANCES (mm) CUTTING DECIMAL METRIC OVERALL FLUTE CLEARED UNCOATED Ti-NAMITE-A D1 = +0,0000/–0,0127 DIAMETER EQUIV. EQUIV. LENGTH LENGTH LENGTH (AlTiN) D1 L1 L2 L3 #23 0.1540 3.91 2-1/2 1-3/8 1-7/64 51023 57142 STEELS 5/32 0.1562 3.97 2-1/2 1-3/8 1-7/64 51110 57143 #22 0.1570 3.99 2-1/2 1-3/8 1-7/64 51022 57144 STAINLESS STEELS 4,0 mm 0.1575 75,0 43,0 34,0 61019 68277 CAST IRON #21 0.1590 4.04 2-1/2 1-3/8 1-7/64 51021 57145 #20 0.1610 4.09 2-1/2 1-3/8 1-7/64 51020 57146 HIGH TEMP ALLOYS 4,1 mm 0.1614 75,0 43,0 34,0 61076 68318 TITANIUM 4,2 mm 0.1654 75,0 43,0 34,0 61077 68319 #19 0.1660 4.22 2-1/2 1-5/8 1-19/64 51019 57147 HARDENED STEELS 4,3 mm 0.1693 80,0 47,0 37,0 61078 68320 NON-FERROUS #18 0.1695 4.31 2-3/4 1-5/8 1-19/64 51018 57148 11/64 0.1719 4.37 2-3/4 1-5/8 1-19/64 51111 57149 PLASTICS/COMPOSITES #17 0.1730 4.39 2-3/4 1-5/8 1-19/64 51017 57150 4,4 mm 0.1732 80,0 47,0 37,0 61079 68321 For patent #16 0.1770 4.50 2-3/4 1-5/8 1-19/64 51016 57151 information visit 4,5 mm 0.1772 80,0 47,0 37,0 61021 68278 www.ksptpatents.com #15 0.1800 4.57 2-3/4 1-5/8 1-19/64 51015 57152 4,6 mm 0.1811 80,0 47,0 37,0 61080 68322 #14 0.1820 4.62 2-3/4 1-5/8 1-19/64 51014 57153 4,7 mm 0.1850 80,0 47,0 37,0 61081 68323 #13 0.1850 4.70 2-3/4 1-5/8 1-19/64 51013 57154 *3/16 0.1875 4.76 2-3/4 1-5/8 1-19/64 51112 57155 4,8 mm 0.1890 86,0 52,0 41,0 61082 68324 #12 0.1890 4.80 2-3/4 1-5/8 1-19/64 51012 57156 #11 0.1910 4.85 2-3/4 1-5/8 1-19/64 51011 57157 4,9 mm 0.1929 86,0 52,0 41,0 61083 68325 #10 0.1935 4.91 2-3/4 1-5/8 1-19/64 51010 57158 #9 0.1960 4.98 3 1-3/4 1-13/32 51009 57159 5,0 mm 0.1969 86,0 52,0 41,0 61023 68279 #8 0.1990 5.05 3 1-3/4 1-13/32 51008 57160 5,1 mm 0.2008 86,0 52,0 41,0 61084 68326 #7 0.2010 5.11 3 1-3/4 1-13/32 51007 57161 13/64 0.2031 5.16 3 1-3/4 1-13/32 51113 57162 #6 0.2040 5.18 3 1-3/4 1-13/32 51006 57163 5,2 mm 0.2047 86,0 52,0 41,0 61085 68327 #5 0.2055 5.22 3 1-3/4 1-13/32 51005 57164 5,3 mm 0.2087 86,0 52,0 41,0 61086 68328 #4 0.2090 5.31 3 1-3/4 1-13/32 51004 57165 5,4 mm 0.2126 93,0 57,0 45,0 61087 68329 #3 0.2130 5.41 3 1-3/4 1-13/32 51003 57166 5,5 mm 0.2165 93,0 57,0 1-13/32 61025 68280 7/32 0.2188 5.56 3 1-3/4 1-13/32 51114 57167 5,6 mm 0.2205 93,0 57,0 45,0 61088 68330 #2 0.2210 5.61 3 1-3/4 1-13/32 51002 57168 continued on next page 290 DRILLS www.kDyRoIcLeLrSa-sgstool.com
