30° POS 15° 4
| APMX | LF | ||||||
| TOLERANCES() | DCON | ||||||
| mm | DC | M | |||||
| 0,4–3,0DIAMETER | RE | ||||||
| DC =+0,0000/–0,0254 | |||||||
| DCON =h6 | mm | ED | P NO. | ||||
| STEELS | CUTTING DIAMETER DC | DECIMAL EQUIVALENT | SHANK DIAMETER DCON | LENGTH OF CUT APMX | OVERALL LENGTH LF | UNCOATED | TI-NAMITE-A (AlTiN) |
| 0,4 | 0.0157 | 3,0 | 1,2 | 38,0 | 05043 | 05031 | |
| STAINLESS STEELS | 0,5 | 0.0197 | 3,0 | 1,5 | 38,0 | 05045 | 05033 |
| CAST IRON | 0,6 | 0.0236 | 3,0 | 1,8 | 38,0 | 05047 | 05035 |
| HIGH TEMP ALLOYS | 0,7 | 0.0276 | 3,0 | 2,1 | 38,0 | 05049 | 05037 |
| 0,8 | 0.0315 | 3,0 | 2,4 | 38,0 | 05051 | 05039 | |
| TITANIUM | 0,9 | 0.0354 | 3,0 | 2,7 | 38,0 | 05053 | 05041 |
| HARDENED STEELS | 1,0 | 0.0394 | 3,0 | 3,0 | 38,0 | 01979 | 02839 |
| 1,0 | 0.0394 | 4,0 | 3,0 | 50,0 | 02075 | 03215 | |
| NON-FERROUS | 1,1 | 0.0433 | 3,0 | 3,3 | 38,0 | 01980 | 02960 |
| PLASTICS/COMPOSITES | 1,1 | 0.0433 | 4,0 | 3,3 | 50,0 | 02076 | 03016 |
| 1,2 | 0.0472 | 3,0 | 3,6 | 38,0 | 01981 | 02961 | |
| 1,2 | 0.0472 | 4,0 | 3,6 | 50,0 | 02077 | 03017 | |
| 1,3 | 0.0512 | 3,0 | 3,9 | 38,0 | 01982 | 02962 | |
| 1,3 | 0.0512 | 4,0 | 3,9 | 50,0 | 02078 | 03018 | |
| 1,4 | 0.0551 | 3,0 | 4,2 | 38,0 | 01983 | 02963 | |
| 1,4 | 0.0551 | 4,0 | 4,2 | 50,0 | 02079 | 03019 | |
| 1,5 | 0.0591 | 3,0 | 4,5 | 38,0 | 01984 | 02964 | |
| 1,5 | 0.0591 | 4,0 | 4,5 | 50,0 | 02080 | 03020 | |
| 1,6 | 0.0630 | 3,0 | 4,8 | 38,0 | 01985 | 02965 | |
| 1,6 | 0.0630 | 4,0 | 4,8 | 50,0 | 02081 | 03021 | |
| 1,7 | 0.0669 | 3,0 | 5,1 | 38,0 | 01986 | 02966 | |
| 1,7 | 0.0669 | 4,0 | 5,1 | 50,0 | 02082 | 03022 | |
| 1,8 | 0.0709 | 3,0 | 5,4 | 38,0 | 01987 | 02967 | |
| 1,8 | 0.0709 | 4,0 | 5,4 | 50,0 | 02083 | 03023 | |
| 1,9 | 0.0748 | 3,0 | 5,7 | 38,0 | 01988 | 02968 | |
| 1,9 | 0.0748 | 4,0 | 5,7 | 50,0 | 02084 | 03024 | |
| 2,0 | 0.0787 | 3,0 | 6,0 | 38,0 | 01989 | 02969 | |
| 2,0 | 0.0787 | 4,0 | 6,0 | 50,0 | 02085 | 03025 | |
| 2,1 | 0.0827 | 3,0 | 6,3 | 38,0 | 01990 | 02970 | |
| 2,2 | 0.0866 | 3,0 | 6,6 | 38,0 | 01991 | 02971 | |
| 2,3 | 0.0906 | 3,0 | 6,9 | 38,0 | 01992 | 02972 | |
| 2,4 | 0.0945 | 3,0 | 7,2 | 38,0 | 01993 | 02973 | |
| 2,5 | 0.0984 | 3,0 | 7,5 | 38,0 | 01994 | 02974 | |
| 2,5 | 0.0984 | 4,0 | 7,5 | 50,0 | 02086 | 03026 | |
| 2,6 | 0.1024 | 3,0 | 7,8 | 38,0 | 01995 | 02975 | |
| 2,7 | 0.1063 | 3,0 | 8,1 | 38,0 | 01996 | 02976 | |
| 2,8 | 0.1102 | 3,0 | 8,4 | 38,0 | 01997 | 02977 | |
| 2,9 | 0.1142 | 3,0 | 8,7 | 38,0 | 01998 | 02978 | |
| 3,0 | 0.1181 | 3,0 | 9,0 | 38,0 | 01999 | 02979 | |
| 3,0 | 0.1181 | 4,0 | 9,0 | 50,0 | 02087 | 03027 |
- Proprietary coating
and value, even at low
designed specifically for
of cut, to ensure
that extend tool life,
- All tools in stock to
manufactured in
RE = 1/2 Cutting Diameter (DC)
