| 30° | 15° | POS | 3 | |||||
| New Expanded | Tools | APMX | LF | DCON | ||||
| TOLERANCES(inch) | 3B | • 3D | ||||||
| DC | x | |||||||
| .010–.120DIAMETER DC =+0.000/–0.001 | RE | FRAC | TIONAL SERIES | |||||
| DCON =h6 | in | ch | EDP | NO. | continued | |||
| STEELS | CUTTING DIAMETER DC | SHANK DIAMETER DCON | LENGTH OF CUT APMX | OVERALL LENGTH LF U | NCOATED | TI-NAMITE-A (AlTiN) | ||
| STAINLESS STEELS | 0.044 | 1/8 | 0.132 | 1-1/2 | 01467 | 04422 | ||
| 0.045 | 1/8 | 0.135 | 1-1/2 | 01468 | 04423 | |||
| CAST IRON | 0.046 | 1/8 | 0.138 | 1-1/2 | 01469 | 04424 | ||
| HIGH TEMP ALLOYS | 0.047 | 1/8 | 0.141 | 1-1/2 | 01470 | 04425 | ||
| TITANIUM | 0.048 | 1/8 | 0.144 | 1-1/2 | 01471 | 04426 | ||
| 0.049 | 1/8 | 0.147 | 1-1/2 | 01472 | 04427 | |||
| HARDENED STEELS | 0.050 | 1/8 | 0.150 | 1-1/2 | 01473 | 04428 | ||
| NON-FERROUS | 0.051 | 1/8 | 0.153 | 1-1/2 | 01474 | 04429 | ||
| PLASTICS/COMPOSITES | 0.052 | 1/8 | 0.156 | 1-1/2 | 01475 | 04430 | ||
| 0.053 | 1/8 | 0.159 | 1-1/2 | 01476 | 04431 | |||
| 0.054 | 1/8 | 0.162 | 1-1/2 | 01477 | 04432 | |||
| 0.055 | 1/8 | 0.165 | 1-1/2 | 01478 | 04433 | |||
| 0.056 | 1/8 | 0.168 | 1-1/2 | 01479 | 04434 | |||
| 0.057 | 1/8 | 0.171 | 1-1/2 | 01480 | 04435 | |||
| 0.058 | 1/8 | 0.174 | 1-1/2 | 01481 | 04436 | |||
| 0.059 | 1/8 | 0.177 | 1-1/2 | 01482 | 04437 | |||
| 0.060 | 1/8 | 0.180 | 1-1/2 | 01483 | 04438 | |||
| 0.062 | 1/8 | 0.186 | 1-1/2 | 01484 | 04439 | |||
| 0.065 | 1/8 | 0.195 | 1-1/2 | 01485 | 04440 | |||
| 0.070 | 1/8 | 0.210 | 1-1/2 | 01486 | 04441 | |||
| 0.075 | 1/8 | 0.225 | 1-1/2 | 01487 | 04442 | |||
| 0.078 | 1/8 | 0.234 | 1-1/2 | 01488 | 04443 | |||
| 0.080 | 1/8 | 0.240 | 1-1/2 | 01489 | 04444 | |||
| 0.085 | 1/8 | 0.255 | 1-1/2 | 01490 | 04445 | |||
| 0.090 | 1/8 | 0.270 | 1-1/2 | 01491 | 04446 | |||
| 0.093 | 1/8 | 0.279 | 1-1/2 | 01492 | 04447 | |||
| 0.095 | 1/8 | 0.285 | 1-1/2 | 01493 | 04448 | |||
| 0.100 | 1/8 | 0.300 | 1-1/2 | 01494 | 04449 | |||
| 0.105 | 1/8 | 0.315 | 1-1/2 | 01495 | 04450 | |||
| 0.110 | 1/8 | 0.330 | 1-1/2 | 01496 | 04451 | |||
| 0.115 | 1/8 | 0.345 | 1-1/2 | 01497 | 04452 | |||
| 0.120 | 1/8 | 0.360 | 1-1/2 | 01498 | 04453 |
RE = 1/2 Cutting Diameter (DC)
