METRIC 2 Flute Internal Coolant 28° 140° 2 OAL LCF LU DCON TOLERANCES (mm) 1,0–4,0 DIAMETER DC M814 METRIC SERIES DC = +0,000/–0,008 mm EDP NO. DCON = h 6 continued CUTTING DECIMAL SHANK FLUTE CLEARED OVERALL DIAMETER EQUIVALENT DIAMETER LENGTH LENGTH LENGTH TI-NAMITE-CR STEELS DC DCON LCF LU OAL (AlCrN) 1,3 0.0512 4,0 24,8 19,5 64,0 06034 STAINLESS STEELS 1,4 0.0551 4,0 26,3 21,0 64,0 06035 CAST IRON 1,5 0.0591 4,0 27,8 22,5 64,0 06036 HIGH TEMP ALLOYS 1,6 0.0630 4,0 29,3 24,0 81,0 06037 TITANIUM 1,7 0.0669 4,0 30,8 25,5 81,0 06038 1,8 0.0709 4,0 33,0 27,0 81,0 06039 HARDENED STEELS 1,9 0.0748 4,0 34,5 28,5 81,0 06040 NON-FERROUS 2,0 0.0787 4,0 36,0 30,0 81,0 06041 PLASTICS/COMPOSITES 2,1 0.0827 4,0 37,5 31,5 81,0 06042 2,2 0.0866 4,0 41,1 33,0 81,0 06043 2,3 0.0906 4,0 42,6 34,5 81,0 06044 2,4 0.0945 4,0 44,1 36,0 81,0 06045 2,5 0.0984 4,0 45,6 37,5 90,0 06046 2,6 0.1024 4,0 47,1 39,0 90,0 06047 2,7 0.1063 4,0 48,6 40,5 90,0 06048 2,8 0.1102 4,0 50,1 42,0 90,0 06049 2,9 0.1142 4,0 52,5 43,5 90,0 06050 3,0 0.1181 4,0 54,0 45,0 90,0 06051 3,1 0.1220 4,0 55,5 46,5 106,0 06052 3,2 0.1260 4,0 57,0 48,0 106,0 06053 3,3 0.1299 4,0 58,5 49,5 106,0 06054 3,4 0.1339 4,0 61,9 51,0 106,0 06055 3,5 0.1378 4,0 63,4 52,5 106,0 06056 3,6 0.1417 4,0 64,9 54,0 106,0 06057 3,7 0.1457 4,0 66,4 55,5 106,0 06058 3,8 0.1496 4,0 67,9 57,0 106,0 06059 3,9 0.1535 4,0 69,4 58,6 106,0 06060 4,0 0.1575 4,0 70,9 60,0 106,0 06061 135 DRILLS www.sgsmicrotools.com DRILLS
