Grinding Disks / Dressers 28 mm CVD needle dresser Design: - optimal dressing tool for achieving consistent surface quality - constant effective width throughout the entire wearing process 10 mm Advantages over conventional dressing plates: Due to the uniformity of the CVD diamond needles, the reproducibility of the work sequence or the dressing results (surface structure of the grinding wheel and wear characteristics of the dressing tool) is almost constant Note: Further needle thicknesses and lengths as well as PKD versions on request with 3 needles 469390 Dressing plate, CVD Type 469390 Dimensions of CVD needles:mm AP101/633C  0.6 × 0.6 × 3 AP101/653C  0.6 × 0.6 × 5 AP101/833C  0.8 × 0.8 × 3 AP101/853C  0.8 × 0.8 × 5 AP101/1043C  1.0 × 1.0 × 4 AP101/1053C  1.0 × 1.0 × 5 Diamond multi-grain dresser Design: Dressing surface interspersed with several rows of diamond grain (2.75 carat) Diamond F1 = transverse to the shaft F2 = parallel to the shaft Use: For planing, profiling and dressing of straight grinding disks 469400 with handle F1 Type 469400 Coating area length × widthmm Total lengthmm F1  30 × 10 200 46 F2  30 × 10 200 F2 Diamond single-grain dresser Design: - cylindrical 8 × 80 mm - for dressing of grinding disks K60 - 180 Diamond Diamond weight carat 469490 0,5  0,75  Diamond fine-grain dresser 469490 Single-grain dresser Design: - cylindrical 8 × 80 mm - for the dressing of grinding disks K60 - 180 on cylindrical and flat grinders Diamond Note: Coarser or finer graining available on request 469492 Fine-grain dresser Diamond weight carat 469492 1,2  46/854 www.precitool.de
