Grinding Disks / Dressers Diamond single-grain dresser with natural diamond tip Design: - 1st quality = diamonds with 3 - 5 sharp points - 2nd quality = diamonds with 1 - 3 sharp points Diamond Use: - for dressing, profiling and sharpening of EK and SC grinding disks - diamond dresser should be clamped vibration-free and as short as possible Note: Further sizes available on request *Shank diameter and length at your choice Without particulars we provide Ø 10 × 50 mm Substitution or applying of new stones is possible!On request also diamonds up to 5 carats available!Carat weight . . . . . for disk Ø 469500 1st quality mm 469550 2nd quality Diamond weightcarat/shank469500 469550 Diamond weightcarat/shank 469500 469550 Diamond weightcarat/shank 469500 469550 0,33MK1  — 0,80MK0   0,3ZYL.   0,50MK0  — 0,80MK1   0,6ZYL.   0,50MK1   1,0MK0   0,8ZYL.   0,60MK0   1,0MK1   — — — Diamond multi-grain dresser with tips of natural diamonds Design: - wearing a number of finely crystallised, sharp crude natural diamonds - arranged either in one or in several layers Diamond - shank sizes MK 0, MK 1 Use: - for dressing, profiling and sharpening of EK and SC grinding disks - diamond dresser should be clamped vibration-free and as short as possible - suited for coarse and robust dressing Note: Further sizes available on request 469580 Shank size MK 0 MA 4 MA 7 MA 8 46 469600 Shank size MK 1 Type 469580 469600 Diamond weightCaratDiamond application × depthmmDiamond dispersion Application note: MA4   2.50 10 × 10 5 layers with 13 stones apiece Universally applicable for all grinding disks from grain 46 MA7   2.50 12 × 10 5 layers with 25 stones apiece Universally applicable for all grinding disks with medium and fine grain MA8   5.00 12 × 12   interspersed for large and wide disks with fine grain Diamond fine-grain dresser Diamond dressing plate Design: Design: - cylindrical 10 × 50 mm - for dressing of grinding disks K60 - 180 on - for the dressing of grinding disks K60 - 180 Diamond cylindrical grinding machines Diamond on cylindrical and flat grinders - for finer disks, finer diamond grain sizes are - quality D711 available Note: Note: Further sizes available on request Other dimensions, natural sharp points and CVD Coarser or finer graining available on request dressing plates available on request 469605 Shank size MK0 469607 Shank size MK1 469609 Shank size cylindrical 10 × 50 mm 469610 Grit D 900 Diamond weight carat 469605 469607 469609 Type 469610 2,5    AP105  3,5    AP205  www.precitool.de 46/855
