Optical / Device Monitoring Profile projector Design: - table top version to control small and medium size workpieces - vertical, rotatable cross-hair monitor - easy to operate coordinate plane table with quick and fine adjustment - direct and clearly visible XY digital display - halogen transmitted light and incident illumination (24 V / 150 W) are installed in the housing - as standard equipped with digital angle measurement display - monitor x 315 mm / 12.4" - as standard lens 10-fold - max. workpiece weight 8 kg A3010 392950 MITUTOYO 302, table version, vertical Type 392950 Size of measuring tablemm Travelmm Weightkg A3005 + 280 × 152 150 × 50 116 A3010 + 380 × 250 200 × 100 140 Profile projector Design: 39 - robust floor-mounted version- large, rotatable monitor- monitor x 508 mm / 20" - halogen transmitted light and incident light 24 V / 150 W - as standard lens 10-fold - max. workpiece weight 5 kg 392951 MITUTOYO 304, floor-mounted version Type 392951 Size of measuring tablemm Travelmm Weightkg PV5110 + 380 × 250 200 × 100 210 Digital length measuring system Linear Scale Design: - effective measuring range from 100 to 3000 mm available - max. speed 50 m/min IP67 - operation temperature from 0° to +45 °C - dust- and water-protected (IP67) - automatic zero point setting after power on 393000 MITUTOYO 539, AT715 Type 393000 Measuring range max. measuring head path Cable lengthmm/inchmmm 0100 100/ 4“ 120 3.5 0150 150/ 6“ 170 3.5 0200 200/ 8“ 220 3.5 0250 250/10“ 270 3.5 0300 300/12“ 330 3.5 0350 350/14“ 380 3.5 0400 400/16“ 430 3.5 0450 450/18“ 480 3.5 0500 500/20“ 540 3.5 0600 600/24“ 640 3.5 0700 700/28“ 740 3.5 0750 750/30“ 780 3.5 0800 800/32“ 840 3.5 0900 900/36“ 940 3.5 1000 1000/40“ 1040 5.0 39/768 www.precitool.de
