Dial Gauges/ Length Measuring Digital dial gauge IP42 Design: - inductive measuring system ABS - data output optional USB, OPTO RS 232 C, DIGIMATIC IP42 TOL Digimatic RS 232 C USB - data in connection with data cable - operation speed 1.5 m/s - detachable protection cap at the end of the spindle - mm/inch selection Functions: - ON/OFF, RESET (zero-setting of the display) - PRESET (presetting of fixed values) - ABS (display can be set to zero without losing the reference to PRESET) - 0 (mode of tolerance indication) Delivery: With battery Note: Fitting connection cable see under 398010 320615 320620 320615 MAHR 1086 R, with data output, 0.01 mm Measuring spanmm 320615 Readingmm/inch Error limitmm12,50.01/.0005"0.02RepeatabilityMeasuring force a b cmm0.010N0.65-0.90mm126.3mm23.0mm 13.532 25  0.01/.0005" 0.02 0.010 0.65-1.15 153.4 26.8  26.5 50  0.01/.0005" 0.02 0.010 1.25-2.70 267.3 40.0  52.0 100  0.01/.0005" 0.02 0.010 1.60-3.50 420.3 91.0 103.0 320620 MAHR 1086 R, with data output, 0.001 mm Measuring spanmm 320620 Repeatabilitymm Measuring forceN amm b c Error limitmmmmmm 12,5  0.001 0.65-0.90 126.3 23.0  13.5 0.004 25  0.001 0.65-1.15 153.4 26.8  26.5 0.004 50  0.001 1.25-2.70 267.3 40.0  52.0 0.004 100  0.001 1.60-3.50 420.3 91.0 103.0 0.004 Digital dial gauge IP42 Design: - one-time setting of the starting position ABS (remains the absolute zero point until the battery is changed) IP42 Digimatic USB U-WAVE® - measuring precision even at high speed - easy reading due to large display characters - 6-digit LCD display - digit height 9 mm - with reversal of counting direction - contact point made of carbide ball - low voltage or counting error alert - measuring force ≤ 2.0 N- cover flat ABSOLUTE - die cast housing - with factory calibration certificate Note: Fitting connection cable see under 398000 320616 MITUTOYO 543, with data output, 0.01 mm Measuring spanmm 320616 Readingmm Error limit Clamping shank  h6mmmm 12,7  0.01 0.004 8 www.precitool.de 32/691
