- specially developed ultra-fine grain carbide VHM 30 × D ICS
- specially developed high-performance coating 130° - specially developed tip geometry coated - degressive spiral groove with patented geometry - with integrated cooling
Cutting data
Note: 10 Set pilot bore with 102414 or 102416, resp. Minimum coolant pressure: Speed ≤ 10,000 rpm. = 15 bar > 10.000 rpm. = 30 bar
130° d d (h6)
1 2 (-0,003 -0,006) 4
102476 MIKRON TOOL, CrazyDrill Flex SST-Inox, 30 × D, eXedur, with internal cooling
| Type | 102476 | d1 mm | l1 mm | l2 mm | l4 mm | d2 mm | Type | 102476 | d1 mm | l1 mm | l2 mm | l4 mm | d2 mm | Type | 102476 | d1 mm | l1 mm | l m | 2 m | l4 mm | d2 mm | |||
| 0030 | | 0�30 | 50 | 2�9 | 9�0 | 3 | 1 | 0061 | | 0�61 | 53 | 6�0 | 18�3 | 3 | 5 | 0092 | | 0�92 | 64 | 9 | �0 | 27�6 | 3 | 5 |
| 0031 | | 0�31 | 50 | 3�0 | 9�3 | 3 | 5 | 0062 | | 0�62 | 53 | 6�1 | 18�6 | 3 | 5 | 0093 | | 0�93 | 64 | 9 | �1 | 27�9 | 3 | 5 |
| 0032 | | 0�32 | 50 | 3�1 | 9�6 | 3 | 5 | 0063 | | 0�63 | 53 | 6�2 | 18�9 | 3 | 5 | 0094 | | 0�94 | 64 | 9 | �2 | 28�2 | 3 | 5 |
| 0033 | | 0�33 | 50 | 3�2 | 9�9 | 3 | 5 | 0064 | | 0�64 | 53 | 6�3 | 19�2 | 3 | 5 | 0095 | | 0�95 | 64 | 9 | �3 | 28�5 | 3 | 1 |
| 0034 | | 0�34 | 50 | 3�3 | 10�2 | 3 | 5 | 0065 | | 0�65 | 53 | 6�4 | 19�5 | 3 | 1 | 0096 | | 0�96 | 64 | 9 | �4 | 28�8 | 3 | 5 |
| 0035 | | 0�35 | 50 | 3�4 | 10�5 | 3 | 1 | 0066 | | 0�66 | 53 | 6�5 | 19�8 | 3 | 5 | 0097 | | 0�97 | 64 | 9 | �5 | 29�1 | 3 | 5 |
| 0036 | | 0�36 | 50 | 3�5 | 10�8 | 3 | 5 | 0067 | | 0�67 | 53 | 6�6 | 20�1 | 3 | 5 | 0098 | | 0�98 | 64 | 9 | �6 | 29�4 | 3 | 5 |
| 0037 | | 0�37 | 50 | 3�6 | 11�1 | 3 | 5 | 0068 | | 0�68 | 53 | 6�7 | 20�4 | 3 | 5 | 0099 | | 0�99 | 64 | 9 | �7 | 29�7 | 3 | 5 |
| 0038 | | 0�38 | 50 | 3�7 | 11�4 | 3 | 5 | 0069 | | 0�69 | 53 | 6�8 | 20�7 | 3 | 5 | 0100 | | 1�00 | 70 | 9 | �8 | 30�0 | 3 | 1 |
| 0039 | | 0�39 | 50 | 3�8 | 11�7 | 3 | 5 | 0070 | | 0�70 | 60 | 6�9 | 21�0 | 3 | 1 | 0101 | | 1�01 | 70 | 9 | �9 | 30�3 | 3 | 5 |
| 0040 | | 0�40 | 50 | 3�9 | 12�0 | 3 | 1 | 0071 | | 0�71 | 60 | 7�0 | 21�3 | 3 | 5 | 0102 | | 1�02 | 70 | 10 | �0 | 30�6 | 3 | 5 |
| 0041 | | 0�41 | 50 | 4�0 | 12�3 | 3 | 5 | 0072 | | 0�72 | 60 | 7�1 | 21�6 | 3 | 5 | 0103 | | 1�03 | 70 | 10 | �1 | 30�9 | 3 | 5 |
| 0042 | | 0�42 | 50 | 4�1 | 12�6 | 3 | 5 | 0073 | | 0�73 | 60 | 7�2 | 21�9 | 3 | 5 | 0104 | | 1�04 | 70 | 10 | �2 | 31�2 | 3 | 5 |
| 0043 | | 0�43 | 50 | 4�2 | 12�9 | 3 | 5 | 0074 | | 0�74 | 60 | 7�3 | 22�2 | 3 | 5 | 0105 | | 1�05 | 70 | 10 | �3 | 31�5 | 3 | 1 |
| 0044 | | 0�44 | 50 | 4�3 | 13�2 | 3 | 5 | 0075 | | 0�75 | 60 | 7�4 | 22�5 | 3 | 1 | 0106 | | 1�06 | 70 | 10 | �4 | 31�8 | 3 | 5 |
| 0045 | | 0�45 | 50 | 4�4 | 13�5 | 3 | 1 | 0076 | | 0�76 | 60 | 7�4 | 22�8 | 3 | 5 | 0107 | | 1�07 | 70 | 10 | �5 | 32�1 | 3 | 5 |
| 0046 | | 0�46 | 50 | 4�5 | 13�8 | 3 | 5 | 0077 | | 0�77 | 60 | 7�5 | 23�1 | 3 | 5 | 0108 | | 1�08 | 70 | 10 | �6 | 32�4 | 3 | 5 |
| 0047 | | 0�47 | 50 | 4�6 | 14�1 | 3 | 5 | 0078 | | 0�78 | 60 | 7�6 | 23�4 | 3 | 5 | 0109 | | 1�09 | 70 | 10 | �7 | 32�7 | 3 | 5 |
| 0048 | | 0�48 | 50 | 4�7 | 14�4 | 3 | 5 | 0079 | | 0�79 | 60 | 7�7 | 23�7 | 3 | 5 | 0110 | | 1�10 | 70 | 10 | �8 | 33�0 | 3 | 1 |
| 0049 | | 0�49 | 50 | 4�8 | 14�7 | 3 | 5 | 0080 | | 0�80 | 60 | 7�8 | 24�0 | 3 | 1 | 0111 | | 1�11 | 70 | 10 | �9 | 33�3 | 3 | 5 |
| 0050 | | 0�50 | 53 | 4�9 | 15�0 | 3 | 1 | 0081 | | 0�81 | 60 | 7�9 | 24�3 | 3 | 5 | 0112 | | 1�12 | 70 | 11 | �0 | 33�6 | 3 | 5 |
| 0051 | | 0�51 | 53 | 5�0 | 15�3 | 3 | 5 | 0082 | | 0�82 | 60 | 8�0 | 24�6 | 3 | 5 | 0113 | | 1�13 | 70 | 11 | �1 | 33�9 | 3 | 5 |
| 0052 | | 0�52 | 53 | 5�1 | 15�6 | 3 | 5 | 0083 | | 0�83 | 60 | 8�1 | 24�9 | 3 | 5 | 0114 | | 1�14 | 70 | 11 | �2 | 34�2 | 3 | 5 |
| 0053 | | 0�53 | 53 | 5�2 | 15�9 | 3 | 5 | 0084 | | 0�84 | 60 | 8�2 | 25�2 | 3 | 5 | 0115 | | 1�15 | 70 | 11 | �3 | 34�5 | 3 | 1 |
| 0054 | | 0�54 | 53 | 5�3 | 16�2 | 3 | 5 | 0085 | | 0�85 | 64 | 8�3 | 25�5 | 3 | 1 | 0116 | | 1�16 | 70 | 11 | �4 | 34�8 | 3 | 5 |
| 0055 | | 0�55 | 53 | 5�4 | 16�5 | 3 | 1 | 0086 | | 0�86 | 64 | 8�4 | 25�8 | 3 | 5 | 0117 | | 1�17 | 70 | 11 | �5 | 35�1 | 3 | 5 |
| 0056 | | 0�56 | 53 | 5�5 | 16�8 | 3 | 5 | 0087 | | 0�87 | 64 | 8�5 | 26�1 | 3 | 5 | 0118 | | 1�18 | 70 | 11 | �6 | 35�4 | 3 | 5 |
| 0057 | | 0�57 | 53 | 5�6 | 17�1 | 3 | 5 | 0088 | | 0�88 | 64 | 8�6 | 26�4 | 3 | 5 | 0119 | | 1�19 | 70 | 11 | �7 | 35�7 | 3 | 5 |
| 0058 | | 0�58 | 53 | 5�7 | 17�4 | 3 | 5 | 0089 | | 0�89 | 64 | 8�7 | 26�7 | 3 | 5 | 0120 | | 1�20 | 70 | 11 | �8 | 36�0 | 3 | 1 |
| 0059 | | 0�59 | 53 | 5�8 | 17�7 | 3 | 5 | 0090 | | 0�90 | 64 | 8�8 | 27�0 | 3 | 1 | — | — | — | — | — | — | — | — | |
| 0060 | | 0�60 | 53 | 5�9 | 18�0 | 3 | 1 | 0091 | | 0�91 | 64 | 8�9 | 27�3 | 3 | 5 | — | — | — | — | — | — | — | — |
