- specially developed ultra-fine grain carbide VHM 50 × D ICS
- specially developed high-performance coating 130° - specially developed tip geometry coated - degressive spiral groove with patented geometry - with integrated cooling
Cutting data 10 Note: Set pilot bore with 102414 or 102416, resp. Minimum coolant pressure: Speed ≤ 10,000 rpm. = 15 bar > 10.000 rpm. = 30 bar
130° d d (h6)
1 2 (-0,003 -0,006) 4
102478 MIKRON TOOL, CrazyDrill Flex SST-Inox, 50 × D, eXedur RIP, with integrated IC
| Type | 102478 | d1 mm | l1 mm | l2 mm | l4 mm | d2 mm | Type | 102478 | d1 mm | l1 mm | l2 m | m | l4 mm | d2 mm | Type | 102478 | d1 mm | l1 mm | l m | 2 m | l4 mm | d2 mm | |||
| 0030 | | 0�30 | 53 | 2�9 | 15�0 | 3 | 1 | 0061 | | 0�61 | 70 | 6 | �0 | 30�5 | 3 | 5 | 0092 | | 0�92 | 85 | 9 | �0 | 46�0 | 3 | 5 |
| 0031 | | 0�31 | 53 | 3�0 | 15�5 | 3 | 5 | 0062 | | 0�62 | 70 | 6 | �1 | 31�0 | 3 | 5 | 0093 | | 0�93 | 85 | 9 | �1 | 46�5 | 3 | 5 |
| 0032 | | 0�32 | 53 | 3�1 | 16�0 | 3 | 5 | 0063 | | 0�63 | 70 | 6 | �2 | 31�5 | 3 | 5 | 0094 | | 0�94 | 85 | 9 | �2 | 47�0 | 3 | 5 |
| 0033 | | 0�33 | 53 | 3�2 | 16�5 | 3 | 5 | 0064 | | 0�64 | 70 | 6 | �3 | 32�0 | 3 | 5 | 0095 | | 0�95 | 85 | 9 | �3 | 47�5 | 3 | 1 |
| 0034 | | 0�34 | 53 | 3�3 | 17�0 | 3 | 5 | 0065 | | 0�65 | 70 | 6 | �4 | 32�5 | 3 | 1 | 0096 | | 0�96 | 85 | 9 | �4 | 48�0 | 3 | 5 |
| 0035 | | 0�35 | 53 | 3�4 | 17�5 | 3 | 1 | 0066 | | 0�66 | 70 | 6 | �5 | 33�0 | 3 | 5 | 0097 | | 0�97 | 85 | 9 | �5 | 48�5 | 3 | 5 |
| 0036 | | 0�36 | 53 | 3�5 | 18�0 | 3 | 5 | 0067 | | 0�67 | 70 | 6 | �6 | 33�5 | 3 | 5 | 0098 | | 0�98 | 85 | 9 | �6 | 49�0 | 3 | 5 |
| 0037 | | 0�37 | 53 | 3�6 | 18�5 | 3 | 5 | 0068 | | 0�68 | 70 | 6 | �7 | 34�0 | 3 | 5 | 0099 | | 0�99 | 85 | 9 | �7 | 49�5 | 3 | 5 |
| 0038 | | 0�38 | 53 | 3�7 | 19�0 | 3 | 5 | 0069 | | 0�69 | 70 | 6 | �8 | 34�5 | 3 | 5 | 0100 | | 1�00 | 85 | 9 | �8 | 50�0 | 3 | 1 |
| 0039 | | 0�39 | 53 | 3�8 | 19�5 | 3 | 5 | 0070 | | 0�70 | 70 | 6 | �9 | 35�0 | 3 | 1 | 0101 | | 1�01 | 90 | 9 | �9 | 50�5 | 3 | 5 |
| 0040 | | 0�40 | 53 | 3�9 | 20�0 | 3 | 1 | 0071 | | 0�71 | 75 | 7 | �0 | 35�5 | 3 | 5 | 0102 | | 1�02 | 90 | 10 | �0 | 51�0 | 3 | 5 |
| 0041 | | 0�41 | 60 | 4�0 | 20�5 | 3 | 5 | 0072 | | 0�72 | 75 | 7 | �1 | 36�0 | 3 | 5 | 0103 | | 1�03 | 90 | 10 | �1 | 51�5 | 3 | 5 |
| 0042 | | 0�42 | 60 | 4�1 | 21�0 | 3 | 5 | 0073 | | 0�73 | 75 | 7 | �2 | 36�5 | 3 | 5 | 0104 | | 1�04 | 90 | 10 | �2 | 52�0 | 3 | 5 |
| 0043 | | 0�43 | 60 | 4�2 | 21�5 | 3 | 5 | 0074 | | 0�74 | 75 | 7 | �3 | 37�0 | 3 | 5 | 0105 | | 1�05 | 90 | 10 | �3 | 52�5 | 3 | 1 |
| 0044 | | 0�44 | 60 | 4�3 | 22�0 | 3 | 5 | 0075 | | 0�75 | 75 | 7 | �4 | 37�5 | 3 | 1 | 0106 | | 1�06 | 90 | 10 | �4 | 53�0 | 3 | 5 |
| 0045 | | 0�45 | 60 | 4�4 | 22�5 | 3 | 1 | 0076 | | 0�76 | 75 | 7 | �4 | 38�0 | 3 | 5 | 0107 | | 1�07 | 90 | 10 | �5 | 53�5 | 3 | 5 |
| 0046 | | 0�46 | 60 | 4�5 | 23�0 | 3 | 5 | 0077 | | 0�77 | 75 | 7 | �5 | 38�5 | 3 | 5 | 0108 | | 1�08 | 90 | 10 | �6 | 54�0 | 3 | 5 |
| 0047 | | 0�47 | 60 | 4�6 | 23�5 | 3 | 5 | 0078 | | 0�78 | 75 | 7 | �6 | 39�0 | 3 | 5 | 0109 | | 1�09 | 90 | 10 | �7 | 54�5 | 3 | 5 |
| 0048 | | 0�48 | 60 | 4�7 | 24�0 | 3 | 5 | 0079 | | 0�79 | 75 | 7 | �7 | 39�5 | 3 | 5 | 0110 | | 1�10 | 90 | 10 | �8 | 55�0 | 3 | 1 |
| 0049 | | 0�49 | 60 | 4�8 | 24�5 | 3 | 5 | 0080 | | 0�80 | 75 | 7 | �8 | 40�0 | 3 | 1 | 0111 | | 1�11 | 95 | 10 | �9 | 55�5 | 3 | 5 |
| 0050 | | 0�50 | 60 | 4�9 | 25�0 | 3 | 1 | 0081 | | 0�81 | 80 | 7 | �9 | 40�5 | 3 | 5 | 0112 | | 1�12 | 95 | 11 | �0 | 56�0 | 3 | 5 |
| 0051 | | 0�51 | 64 | 5�0 | 25�5 | 3 | 5 | 0082 | | 0�82 | 80 | 8 | �0 | 41�0 | 3 | 5 | 0113 | | 1�13 | 95 | 11 | �1 | 56�5 | 3 | 5 |
| 0052 | | 0�52 | 64 | 5�1 | 26�0 | 3 | 5 | 0083 | | 0�83 | 80 | 8 | �1 | 41�5 | 3 | 5 | 0114 | | 1�14 | 95 | 11 | �2 | 57�0 | 3 | 5 |
| 0053 | | 0�53 | 64 | 5�2 | 26�5 | 3 | 5 | 0084 | | 0�84 | 80 | 8 | �2 | 42�0 | 3 | 5 | 0115 | | 1�15 | 95 | 11 | �3 | 57�5 | 3 | 1 |
| 0054 | | 0�54 | 64 | 5�3 | 27�0 | 3 | 5 | 0085 | | 0�85 | 80 | 8 | �3 | 42�5 | 3 | 1 | 0116 | | 1�16 | 95 | 11 | �4 | 58�0 | 3 | 5 |
| 0055 | | 0�55 | 64 | 5�4 | 27�5 | 3 | 1 | 0086 | | 0�86 | 80 | 8 | �4 | 43�0 | 3 | 5 | 0117 | | 1�17 | 95 | 11 | �5 | 58�5 | 3 | 5 |
| 0056 | | 0�56 | 64 | 5�5 | 28�0 | 3 | 5 | 0087 | | 0�87 | 80 | 8 | �5 | 43�5 | 3 | 5 | 0118 | | 1�18 | 95 | 11 | �6 | 59�0 | 3 | 5 |
| 0057 | | 0�57 | 64 | 5�6 | 28�5 | 3 | 5 | 0088 | | 0�88 | 80 | 8 | �6 | 44�0 | 3 | 5 | 0119 | | 1�19 | 95 | 11 | �7 | 59�5 | 3 | 5 |
| 0058 | | 0�58 | 64 | 5�7 | 29�0 | 3 | 5 | 0089 | | 0�89 | 80 | 8 | �7 | 44�5 | 3 | 5 | 0120 | | 1�20 | 95 | 11 | �8 | 60�0 | 3 | 1 |
| 0059 | | 0�59 | 64 | 5�8 | 29�5 | 3 | 5 | 0090 | | 0�90 | 80 | 8 | �8 | 45�0 | 3 | 1 | — | — | — | — | — | — | — | — | |
| 0060 | | 0�60 | 64 | 5�9 | 30�0 | 3 | 1 | 0091 | | 0�91 | 85 | 8 | �9 | 45�5 | 3 | 5 | — | — | — | — | — | — | — | — |
