Clamping Devices Clamping devices and accessories Design: - plane-parallel precision-ground in pairs - size specifications on each piece - pair tolerance tp in height IT5 - nominal size tolerance in height ± 0.01 mm - remaining sizes to DIN ISO 2768m Use: As supports for various machining operations Delivery: In wooden stand 298670 Parallel support set ContentsPair 298670 Contents 1 pair each (W × H)mm Lmm 3 × 11 | 3 × 13 | 3 × 15 | 3 × 16 | 3 × 17 | 3 × 18 2429  3 × 20 | 3 × 21 | 3 × 22 | 3 × 23 | 3 × 25 | 3 × 263 × 27 | 3 × 28 | 3 × 30 | 3 × 31 | 3 × 32 | 3 × 331253 × 35 | 3 × 36 | 3 × 37 | 3 × 38 | 3 × 40 | 3 × 423 × 11 | 3 × 12 | 3 × 13 | 3 × 14 | 3 × 15 | 3 × 16 | 3 × 17 | 3 × 18 32  3 × 19 | 3 × 20 | 3 × 21 | 3 × 22 | 3 × 23 | 3 × 24 | 3 × 25 | 3 × 263 × 27 | 3 × 28 | 3 × 29 | 3 × 30 | 3 × 31 | 3 × 32 | 3 × 33 | 3 × 34125 3 × 35 | 3 × 36 | 3 × 37 | 3 × 38 | 3 × 39 | 3 × 40 | 3 × 41 | 3 × 42 Design: Delivered - spring steel hardened and tempered - height gradation 2 mm in case - material thickness 0.3 mm - pair tolerance tp in height IT5 - nominal size tolerance 10 in height ± 0.004 mm - remaining sizes to DIN ISO 2768m - no swarf on the support surface 298675 Parallel support set, undulated Heightmm 298675 Contents 1 pair each (W × H)mm Lmm 9-23  0.3 ×   9 | 0.3 × 11 | 0.3 × 13 | 0.3 × 150.3 × 17 | 0.3 × 19 | 0.3 × 21 | 0.3 × 23110 25-39  0.3 × 25 | 0.3 × 27 | 0.3 × 29 | 0.3 × 310.3 × 33 | 0.3 × 35 | 0.3 × 37 | 0.3 × 39110 Design: - C15, case-hardened - standardised in pairs, 20 mm wide aligning groove Use: - exchange of the T-nuts allows different groove widths on the machine - for extra heavy fixtures loose type T-nuts 298880 298850 Precision T-nuts, stationary Bmm 298850 Hmm Lmm DIN 84 or DIN 912 Screw 12  10 22 M6 × 10 14  10 25 M6 × 16 16  10 25 M6 × 16 Fixture 18  10 25 M6 × 16221232M6 × 16 Slot nut 28  12 32 M6 × 16 Machine bench Design: C15, case-hardened and ground Use: - cost-effective and practical, in cases where a fixture is always used on the same machine - for extra heavy fixtures loose type T-nuts 298880 298870 Precision T-nuts, low type Bmm 298870 Hmm Lmm DIN 84 or DIN 912 Screw 12  8 20 M5 × 12 14  10 22 M6 × 16161022M6 × 16 Fixture 18  10 22 M6 × 16 Slot nut 20  10 22 M6 × 16221232M6 × 16 Machine bench 29/614 www.precitool.de
