Clamping Devices Clamping devices and accessories Design: - made of coated aluminium profile - steel wedge tempered - clamping of 2 pieces simultaneously - space-saving for multiple clamping - low construction - for round and cubic pieces 297987 Double wedge clamp for the fixture plate Type 297987 Amm B C D E F Allen size Clamping power Starting torquemmmmmmmmmmmmkNNmScrew PU 0001   6.1- 6.7  6.9  8.1  5.3  3.6  6.4  1.5  0.9  0.7 M2 6 0002   9.1-10.0  9.7 11.9  7.9  4.7  9.5  2.0  1.3  1.5 M2.5 6 0003  12.3-13.2 14.5 15.9 10.4  5.6 12.7  3.0  2.2  3.4 M4 8 0004  18.6-20.3 19.0 23.8 16.1  9.5 19.0  5.0  6.7000524.8-26.925.931.720.812.725.4 6.0 8.914.314.5M6M86429 0006  37.3-39.9 38.6 47.6 30.8 19.0 38.1 10.0 15.6 38.4 M12 2 0007  49.7-53.0 51.5 63.5 41.2 25.4 50.8 14.0 26.7 74.6 M16 2 Clamping devices and accessories Design: - case-hardened - ground in pairs plane-parallel in height - pair tolerance tp in height IT 5 - nominal size tolerance in width h7 - nominal size tolerance in height and remaining dimensions to DIN ISO 2760m Use: - for machine grooves, also applicable as parallel supports - parallel stops are primarily intended for small to medium sized machines - thickness aligned to machine grooves with tolerance H8 - several matched pairs available on request 298000 Parallel stop Width(T-slot nom. dim.)mm 298000 bmm h lmmmm in pairs tpmm 8  -0.015  25 100 0.009 10  -0.015  32 100 0.011 12  -0.018  40 100 0.011 14  -0.018  50 100 0.011 16  -0.018  50 160 0.011 18  -0.018  63 160 0.013 20  -0.021  63 160 0.013 22  -0.021  80 160 0.013 24  -0.021  80 160 0.013 28  -0.021 100 160 0.015 Clamping devices and accessories Design and use: - very solid construction of anodised aluminium - adjustable in five axes - for use on drilling and milling machines or as assembly aid - quick adjustable - mounting thread M8 for slot-nut or direct mounting Delivery: With T-nut M8 x 12 mm and hex key 6 mm Note: By exchanging the T-nut applicable on different machines 298150 Workpiece stop Heightmm 298150 150  www.precitool.de 29/611
