Clamping Devices Clamping devices and accessories Design: - made of tempered steel, varnished - with trapezoidal steps, straight form 291150 Clamp with stepped teeth Slot width ×total lengthmm291150 for lockingscrews Bmm Hmm Slot width ×total lengthmm291150 for locking B Hscrewsmmmm 6,6×50  M6 20 10 14×160  M12/M14 40 20 6,6×80  M6 20 10 18×125  M16/M18 50 25 9×60  M8 25 12 18×200  M16/M18 50 25 11×80  M10 30 15 22×160  M20/M22 60 30 14×100  M12/M14 40 20 26×200  M24 70 30 Design: - clamp bevelled, varnished DIN 6314 - complete with adjusting support screw and T-slot screw DIN 787 - individual support screws are available at short notice on request 29 291200 Clamps adjustable Flute width (a)mm 291200 T-boltDIN 787 B H L e1 e2 hmmmmmmmmmmmmFlute width (a)mm291200 T-boltDIN 787 B H L e1 e2 hmmmmmmmmmmmm 10  10 M 10 ×   80 11 15 80 15 30 8-32 16  16 M 16 × 125 18 25 125 26 45 13-48 12  12 M 12 × 100 14 20 100 21 40 10-40 18  18 M 16 × 125 18 25 125 26 45 13-46 14  14 M 12 × 100 14 20 100 21 40 10-38 22  22 M 20 × 160 22 30 160 30 60 16-65 Design: - clamp varnished DIN 6316 - complete with adjusting support screw and T-slot screw DIN 787 - individual support screws are available at short notice on request 291220 Clamp adjustable and cranked Flute width (a)mm 291220 T-boltDIN 787 B H L e1 e2 hmmmmmmmmmmmmFlute width (a)mm291220 T-boltDIN 787 B H L e1 e2 hmmmmmmmmmmmm 10  10 M 10 ×   80 11 15 100 36.0 32 22-46 16  16 M 16 × 125 18 25 160 51.5 50 36-71 12  12 M 12 × 100 14 20 125 44.0 40 28-58 18  18 M 16 × 125 18 25 160 51.5 50 36-69 14  14 M 12 × 100 14 20 125 44.0 40 28-56 — — — — — — — — — Design: - made of tempered steel, burnished - with support screw - clamping screws DIN 787, studs DIN 6379 or socket head cap screws ISO 4762 can be used optionally for clamping 291240 Clamp, lightweight construction Slot width ×total lengthmm291240for lockingscrewsB1mmLmmHmm H1 A B2 B3 E1 E2mmmmmmmmmmmmSlot width ×total lengthmm291240for lockingscrewsB1mmLmmHmmH1A B2 B3 E1 E2mmmmmmmmmmmm 20×160  M20 22 200 16-49.0  8-58 44 49 25 43  89 24×250  M24 26 250 20-120.0 10-130 44  54 30 59 116 20×200  M20 22 200 16-89.5  8-98 44 49 25 44  89 36×315  M30 33 315 18-142.0  7-214 71  72 40 59 152 24×200  M24 26 250 20-69.0 10-81 44 54 30 46 116 48×400  M36 43 400 18-135.0  7-153 80 102 54 74 209 Design and use: - steel, forged and tempered, galvanised - complete with T-bolt DIN 787 - for bridging different clamping heights without additional support - for highest loads - suited for clamping of cutting and punching tools 291400 Clamping claw continuously adjustable T-slot size 291400 T-boltDIN 787 B H Lmmmmmm T-slot size 291400 T-boltDIN 787 B H Lmmmmmm 12  12 M12 × 125 50 0-50 140 16  16 M16 × 160 50 0-75 140 14  14 M12 × 125 50 0-50 140 18  18 M16 × 160 50 0-75 140 www.precitool.de 29/599
