Clamping Devices Clamping devices and accessories Design: Design: - short, through U-bend continuously adjustable - long, goose-necked, through U-bend continuously adjustable - tempered, galvanised, passivated - tempered, galvanised, passivated - without clamping screw - without clamping screw H2 H1 L B2 B2 291420 Clamping claw short with U-bend, forged 291450 Clamping claw long, 29 Slot width B1mm 291420 for lockingscrews Lmm H1mm H2mm B2mm for T-slotsNominal sizemm13M 12880-3530- 553812, 1418M 161300-5542- 845616, 18goose-necked with U-bend, forgedSlot width B1mm291450for lockingscrewsLmmH1mmB2mmfor T-slotsNominal sizemm 22  M 20 140 0-65 50-100 66 20, 22 22  M 20 200 25-50 66 20, 22 26  M 24 174 0-75 54-111 76 24, 28 26  M 24 232 30-70 76 24, 28 32  M 30 200 0-80 62-125 90 36 32  M 30 263 40-75 90 36 Design: Design: - low construction - complete with dowel pin - infinitely adjustable outreach - made of stainless steel - made of alloyed heat-treated steel, forged, black galvanised - complete with mounting set 291455 Power clamp, long version 291456 Pressure pad, smooth 291457 Pressure pad, grooved Type 291455 Clamping power kN M T-slot Hmmmm Vmm000130M12146-6813-110Type291456 291457 Clamping powerkN Amm B Cmmmm 0002  30 M16 18 6-68 16-114 0001   30 19.5 25 18 0003  43 M16 18 5-80 16-134 0002   43 24.0 30 20 0004  49 M20 22 7-88 19-165 0003   49 28.0 36 25 Design: - body made of burnished steel - collet chuck attachment made of anodised, high-strength aluminium - mechanics in the base body protected against dirt and cooling water - all-round clamping edge for mounting on the machine table - bottom side with holder for Zero-Point-System size K20 - with grooves for positioning on zero point clamping modules with indexing 291460 mechanical collet chuck with base body Type 291460 ClampingpowerkN Clamping trokemm max. MdNm Dmm D1mm DAmm Emm Fmm Gmm Hmm H1mm H2mm H3mm H4mm Kmm Lmm Mmm N 0001  11 0.3 40 99 23 117 106 102 80 106 25 35 56 15 13 8 K7 25 M12 Design: - made of anodised, high-strength aluminium - fitting for 291460 - is fixed to the basic element with only one centrally attached screw - workpiece contour is milled with a minimum clamping depth of 2 mm - can be milled off to height H1, allowing new workpiece contours to be introduced - maximum workpiece diameter 90 mm or 140 mm respectively 291462 Collet chuck attachment Type 291462 Dmm  D1mm  D2mm Clamping trokemm Hmm H1mm H2mm 0001   99 23 — 0.3 50 25 — 0003  149 23 99 0.3 50 25 10 29/600 www.precitool.de
