Vices / Clamping Devises Drilling machine vice Design: - body and movable jaws made of special cast - low construction, high precision and large clamping range - the body has an open centre, granting free passage for the drill - exchangeable jaws with horizontal and vertical prisms - stepped for clamping of flat material - threaded spindle with handle and cross bore for secure clamping 271680 Type BON Jaw widthmm 271680 Clamping range Jaw heightmmmm Length Width Height Weight approx.mmmmmmkg 80   70 30 150 140  62  4 100  110 35 280 180  74  9 125  130 40 350 205  85 15 160 + 225 50 460 255 102 29 27 Machine vice Design: - low, robust construction made of special cast - mechanic clamping system - centric clamping through LH and RH thread of the spindle - working area of the spindle covered - the lateral jaw guidance allows simple and precise positioning Use: - centric clamping for milling and planing - the centric clamping allows the machining of different workpiece widths without affecting the centre position of the workpiece - jaws SGN reversible, one side smooth, the other grooved Optional accessories: - extensive assortment of jaws - rotating plate (276100) 273950 Type UZ, mechanic, centric Jaw widthmm 273950 Clamping range Jaw heightmmmm Length Length with crank Height Clamping power WeightmmmmmmkNkg 113  110 31.6 344 358  93.5 15 12.8 135  140 39.6 394 408 106.0 22 19.0 160 + 180 49.6 480 495 124.5 24 31.4 200 + 300 62.6 640 655 142.5 25 51.0 Machine vice Design: - clamping system mechanic/hydraulic - mechanical drive with hand crank - hydraulic power transmission via hydraulic unit with standard jaws - large clamping range - high accuracy - rapid clamping range adjustment - long guidance of the movable jaw - all wearing parts, above all the jaw guides, are hardened and ground - for use on a rotation plate with graduation - base equipped with longitudinal grooves for accurate fixing on the machine table 276010 RB-K (power boosted) Jaw width Amm 276010 size Clamping power WeightkNkg 92  1 25  15.5 113  2 30  24.0 135 + 3 40  39.0 160 + 4 50  60.0 200 + 5 100 112.0 www.precitool.de 27/569
