Vices / Clamping Devises Accessories for machine vices Type UZ and RB Design: For machine vices type UZ, 273950 and type RB, 276010 and 276011. 276200: One side smooth, one side grooved, hardened and ground 276220: With horizontal and vertical ground V-grooves. Hardened, for combination with standard jaw SGN Delivery: Type SGN and SPR per piece. SGN SPR 276200 Standard jaw SGN 276220 V-jaw SPR Jaw widthmm 276200 Jaw widthmm 276220 27 92113  92 113 125  135  135  160  160  200  200  — — Accessories for machine vices Design: Design: - with polished contact edge and graduation Rotation plate with fixing screws and T-nuts. - with mounting screws Use: Use: Fitting for 276010 Fitting for Cat.-No. 273950 on page 27/569. and 276011. for jaw width 113-160 for jaw width 200 276100 Rotation plate 276015 Rotation plate for jaw widthmm 276100 for jaw widthmm 276015 113  113  135  135  160  160  200  200  Precision modular vice Design: - vice in modular principle - with pull-down jaws or quick-change jaws - case-hardened HRC 60 - accuracy 0.02 mm 274000 with adjustable pull-down jaws 274001 with quick-change jaw 274000 274001 for jaw widthmm 274000 274001 Clamping range Jaw heightmmmm L×W×Hmm Weightkg 121 —  150 38 345 ×   95 × 40 12,9 125  — 150 40 345 ×   95 × 40 12,9 146 —  200 48 420 × 125 × 50 25,5 146/1 —  300 48 520 × 125 × 50 29,0 150  — 200 50 420 × 125 × 50 25,5 150/1  — 300 50 520 × 125 × 50 29,0 171 — + 200 58 455 × 145 × 58 37,0 171/1 — + 300 58 555 × 145 × 58 42,0 175 + — 200 60 455 × 145 × 58 37,0 175/1 + — 300 60 555 × 145 × 58 42,0 27/570 www.precitool.de
