- like 102425 and 102427.
Note: Set pilot hole with 102401, 102403 or 102416, resp.
VHM
Cutting data
15 × D ICS
coated 140°
10
l 2 d (k5) d (h6) 1 2
102433 MIKRON TOOL, CrazyDrill Cool, 15 × D, with internal cooling
102435 MIKRON TOOL, CrazyDrill Cool, 15 × D, eXedur RIP, with internal cooling
| Type | 102433 | 102435 | d1 mm | l1 mm | l2 mm | d2 mm | Type | 102433 | 102435 | d1 mm | l1 mm | l2 mm | d2 mm | ||
| 0075 | | | 0�75 | 58�0 | 13�5 | 3 | 1 | 0290 | | | 2�90 | 94�5 | 52�2 | 4 | 1 |
| 0080 | | | 0�80 | 58�0 | 14�4 | 3 | 1 | 0295 | | | 2�95 | 96�0 | 53�1 | 4 | 1 |
| 0085 | | | 0�85 | 60�0 | 15�3 | 3 | 1 | 0300 | | | 3�00 | 100�0 | 54�0 | 6 | 1 |
| 0090 | | | 0�90 | 60�0 | 16�2 | 3 | 1 | 0305 | | | 3�05 | 100�0 | 54�9 | 6 | 1 |
| 0095 | | | 0�95 | 60�0 | 17�1 | 3 | 1 | 0310 | | | 3�10 | 100�0 | 55�8 | 6 | 1 |
| 0100 | | | 1�00 | 64�0 | 18�0 | 4 | 1 | 0315 | | | 3�15 | 103�0 | 56�7 | 6 | 1 |
| 0105 | | | 1�05 | 64�0 | 18�9 | 4 | 1 | 0320 | | | 3�20 | 103�0 | 57�6 | 6 | 1 |
| 0110 | | | 1�10 | 64�0 | 19�8 | 4 | 1 | 0325 | | | 3�25 | 103�0 | 58�5 | 6 | 1 |
| 0115 | | | 1�15 | 66�5 | 20�7 | 4 | 1 | 0330 | | | 3�30 | 103�0 | 59�4 | 6 | 1 |
| 0120 | | | 1�20 | 66�5 | 21�6 | 4 | 1 | 0335 | | | 3�35 | 106�0 | 60�3 | 6 | 1 |
| 0125 | | | 1�25 | 66�5 | 22�5 | 4 | 1 | 0340 | | | 3�40 | 106�0 | 61�2 | 6 | 1 |
| 0130 | | | 1�30 | 69�0 | 23�4 | 4 | 1 | 0345 | | | 3�45 | 106�0 | 62�1 | 6 | 1 |
| 0135 | | | 1�35 | 69�0 | 24�3 | 4 | 1 | 0350 | | | 3�50 | 108�5 | 63�0 | 6 | 1 |
| 0140 | | | 1�40 | 69�0 | 25�2 | 4 | 1 | 0355 | | | 3�55 | 108�5 | 63�9 | 6 | 1 |
| 0145 | | | 1�45 | 71�5 | 26�1 | 4 | 1 | 0360 | | | 3�60 | 108�5 | 64�8 | 6 | 1 |
| 0150 | | | 1�50 | 71�5 | 27�0 | 4 | 1 | 0365 | | | 3�65 | 111�0 | 65�7 | 6 | 1 |
| 0155 | | | 1�55 | 71�5 | 27�9 | 4 | 1 | 0370 | | | 3�70 | 111�0 | 66�7 | 6 | 1 |
| 0160 | | | 1�60 | 74�0 | 28�8 | 4 | 1 | 0375 | | | 3�75 | 111�0 | 67�5 | 6 | 1 |
| 0165 | | | 1�65 | 74�0 | 29�7 | 4 | 1 | 0380 | | | 3�80 | 113�5 | 68�4 | 6 | 1 |
| 0170 | | | 1�70 | 74�0 | 30�6 | 4 | 1 | 0385 | | | 3�85 | 113�5 | 69�3 | 6 | 1 |
| 0175 | | | 1�75 | 76�5 | 31�5 | 4 | 1 | 0390 | | | 3�90 | 113�5 | 70�2 | 6 | 1 |
| 0180 | | | 1�80 | 76�5 | 32�5 | 4 | 1 | 0395 | | | 3�95 | 115�5 | 71�1 | 6 | 1 |
| 0185 | | | 1�85 | 76�5 | 33�3 | 4 | 1 | 0400 | | | 4�00 | 115�5 | 72�0 | 6 | 1 |
| 0190 | | | 1�90 | 79�0 | 34�2 | 4 | 1 | 0410 | | | 4�10 | 121�5 | 73�8 | 6 | 1 |
| 0195 | | | 1�95 | 79�0 | 35�1 | 4 | 1 | 0420 | | | 4�20 | 121�5 | 73�9 | 6 | 1 |
| 0200 | | | 2�00 | 79�0 | 36�0 | 4 | 1 | 0430 | | | 4�30 | 121�5 | 75�7 | 6 | 1 |
| 0205 | | | 2�05 | 81�5 | 36�9 | 4 | 1 | 0440 | | | 4�40 | 121�5 | 76�6 | 6 | 1 |
| 0210 | | | 2�10 | 81�5 | 37�8 | 4 | 1 | 0450 | | | 4�50 | 121�5 | 76�5 | 6 | 1 |
| 0215 | | | 2�15 | 81�5 | 38�7 | 4 | 1 | 0460 | | | 4�60 | 121�5 | 78�2 | 6 | 1 |
| 0220 | | | 2�20 | 84�0 | 39�6 | 4 | 1 | 0470 | | | 4�70 | 131�5 | 84�6 | 6 | 1 |
| 0225 | | | 2�25 | 84�0 | 40�5 | 4 | 1 | 0480 | | | 4�80 | 131�5 | 86�4 | 6 | 1 |
| 0230 | | | 2�30 | 84�0 | 41�4 | 4 | 1 | 0490 | | | 4�90 | 131�5 | 86�2 | 6 | 1 |
| 0235 | | | 2�35 | 86�5 | 42�3 | 4 | 1 | 0500 | | | 5�00 | 131�5 | 88�0 | 6 | 1 |
| 0240 | | | 2�40 | 86�5 | 43�2 | 4 | 1 | 0510 | | | 5�10 | 131�5 | 88�7 | 6 | 1 |
| 0245 | | | 2�45 | 86�5 | 44�1 | 4 | 1 | 0520 | | | 5�20 | 131�5 | 88�4 | 6 | 1 |
| 0250 | | | 2�50 | 89�0 | 45�0 | 4 | 1 | 0530 | | | 5�30 | 131�5 | 90�1 | 6 | 1 |
| 0255 | | | 2�55 | 89�0 | 45�9 | 4 | 1 | 0540 | | | 5�40 | 141�5 | 97�2 | 6 | 1 |
| 0260 | | | 2�60 | 89�0 | 46�8 | 4 | 1 | 0550 | | | 5�50 | 141�5 | 99�0 | 6 | 1 |
| 0265 | | | 2�65 | 91�0 | 47�7 | 4 | 1 | 0560 | | | 5�60 | 141�5 | 98�6 | 6 | 1 |
| 0270 | | | 2�70 | 91�0 | 48�6 | 4 | 1 | 0570 | | | 5�70 | 141�5 | 99�2 | 6 | 1 |
| 0275 | | | 2�75 | 92�5 | 49�5 | 4 | 1 | 0580 | | | 5�80 | 141�5 | 100�9 | 6 | 1 |
| 0280 | | | 2�80 | 92�5 | 50�4 | 4 | 1 | 0590 | | | 5�90 | 141�5 | 100�3 | 6 | 1 |
| 0285 | | | 2�85 | 94�5 | 51�3 | 4 | 1 | 0600 | | | 6�00 | 141�5 | 102�0 | 6 | 1 |
