| Microdrill VHM | ||||||
| Design: - like 102425 and 102427. Note: Set pilot hole with 102401, 102403 or 102416, resp. | VHM coated Cutting data | 10 × D | 140° | ICS | UNI | |
| l2 d1(k5) | d2(h6) |
10
102429 MIKRON TOOL, CrazyDrill Cool, 10 × D, with internal cooling
102431 MIKRON TOOL, CrazyDrill Cool, 10 × D, eXedur RIP, with internal cooling
| Type | 102429 | 102431 | d1 mm | l1 mm | l2 mm | d2 mm | Type | 102429 | 102431 | d1 mm | l1 mm | l2 mm | d2 mm | ||
| 0075 | | | 0�75 | 54�0 | 9�8 | 3 | 1 | 0290 | | | 2�90 | 80�5 | 37�7 | 4 | 1 |
| 0080 | | | 0�80 | 54�0 | 10�4 | 3 | 1 | 0295 | | | 2�95 | 80�5 | 38�4 | 4 | 1 |
| 0085 | | | 0�85 | 56�0 | 11�1 | 3 | 1 | 0300 | | | 3�00 | 85�0 | 39�0 | 6 | 1 |
| 0090 | | | 0�90 | 56�0 | 11�7 | 3 | 1 | 0305 | | | 3�05 | 85�0 | 39�7 | 6 | 1 |
| 0095 | | | 0�95 | 56�0 | 12�4 | 3 | 1 | 0310 | | | 3�10 | 85�0 | 40�3 | 6 | 1 |
| 0100 | | | 1�00 | 59�0 | 13�0 | 4 | 1 | 0315 | | | 3�15 | 86�5 | 41�0 | 6 | 1 |
| 0105 | | | 1�05 | 59�0 | 13�7 | 4 | 1 | 0320 | | | 3�20 | 86�5 | 41�6 | 6 | 1 |
| 0110 | | | 1�10 | 59�0 | 14�3 | 4 | 1 | 0325 | | | 3�25 | 86�5 | 42�3 | 6 | 1 |
| 0115 | | | 1�15 | 59�0 | 15�0 | 4 | 1 | 0330 | | | 3�30 | 86�5 | 42�9 | 6 | 1 |
| 0120 | | | 1�20 | 61�5 | 15�6 | 4 | 1 | 0335 | | | 3�35 | 89�0 | 43�6 | 6 | 1 |
| 0125 | | | 1�25 | 61�5 | 16�3 | 4 | 1 | 0340 | | | 3�40 | 89�0 | 44�2 | 6 | 1 |
| 0130 | | | 1�30 | 61�5 | 16�9 | 4 | 1 | 0345 | | | 3�45 | 89�0 | 44�9 | 6 | 1 |
| 0135 | | | 1�35 | 61�5 | 17�6 | 4 | 1 | 0350 | | | 3�50 | 91�0 | 45�5 | 6 | 1 |
| 0140 | | | 1�40 | 61�5 | 18�0 | 4 | 1 | 0355 | | | 3�55 | 91�0 | 46�2 | 6 | 1 |
| 0145 | | | 1�45 | 63�5 | 18�9 | 4 | 1 | 0360 | | | 3�60 | 91�0 | 46�8 | 6 | 1 |
| 0150 | | | 1�50 | 63�5 | 19�5 | 4 | 1 | 0365 | | | 3�65 | 91�0 | 47�5 | 6 | 1 |
| 0155 | | | 1�55 | 63�5 | 20�2 | 4 | 1 | 0370 | | | 3�70 | 93�0 | 48�1 | 6 | 1 |
| 0160 | | | 1�60 | 66�0 | 20�8 | 4 | 1 | 0375 | | | 3�75 | 93�0 | 48�8 | 6 | 1 |
| 0165 | | | 1�65 | 66�0 | 21�5 | 4 | 1 | 0380 | | | 3�80 | 93�0 | 49�4 | 6 | 1 |
| 0170 | | | 1�70 | 66�0 | 22�1 | 4 | 1 | 0385 | | | 3�85 | 95�0 | 50�1 | 6 | 1 |
| 0175 | | | 1�75 | 66�0 | 22�8 | 4 | 1 | 0390 | | | 3�90 | 95�0 | 50�7 | 6 | 1 |
| 0180 | | | 1�80 | 68�0 | 23�4 | 4 | 1 | 0395 | | | 3�95 | 95�0 | 51�4 | 6 | 1 |
| 0185 | | | 1�85 | 68�0 | 24�1 | 4 | 1 | 0400 | | | 4�00 | 95�0 | 52�0 | 6 | 1 |
| 0190 | | | 1�90 | 68�0 | 24�7 | 4 | 1 | 0410 | | | 4�10 | 98�5 | 53�3 | 6 | 1 |
| 0195 | | | 1�95 | 68�0 | 25�0 | 4 | 1 | 0420 | | | 4�20 | 98�5 | 54�6 | 6 | 1 |
| 0200 | | | 2�00 | 70�0 | 26�0 | 4 | 1 | 0430 | | | 4�30 | 98�5 | 54�2 | 6 | 1 |
| 0205 | | | 2�05 | 70�0 | 26�7 | 4 | 1 | 0440 | | | 4�40 | 98�5 | 55�4 | 6 | 1 |
| 0210 | | | 2�10 | 70�0 | 27�3 | 4 | 1 | 0450 | | | 4�50 | 98�5 | 54�9 | 6 | 1 |
| 0215 | | | 2�15 | 72�0 | 28�0 | 4 | 1 | 0460 | | | 4�60 | 98�5 | 56�1 | 6 | 1 |
| 0220 | | | 2�20 | 72�0 | 28�6 | 4 | 1 | 0470 | | | 4�70 | 106�0 | 61�1 | 6 | 1 |
| 0225 | | | 2�25 | 72�0 | 39�3 | 4 | 1 | 0480 | | | 4�80 | 106�0 | 62�4 | 6 | 1 |
| 0230 | | | 2�30 | 74�0 | 29�9 | 4 | 1 | 0490 | | | 4�90 | 106�0 | 61�7 | 6 | 1 |
| 0235 | | | 2�35 | 74�0 | 30�6 | 4 | 1 | 0500 | | | 5�00 | 106�0 | 63�0 | 6 | 1 |
| 0240 | | | 2�40 | 74�0 | 31�2 | 4 | 1 | 0510 | | | 5�10 | 106�0 | 64�3 | 6 | 1 |
| 0245 | | | 2�45 | 75�5 | 31�9 | 4 | 1 | 0520 | | | 5�20 | 106�0 | 62�4 | 6 | 1 |
| 0250 | | | 2�50 | 75�5 | 32�5 | 4 | 1 | 0530 | | | 5�30 | 106�0 | 63�6 | 6 | 1 |
| 0255 | | | 2�55 | 75�5 | 33�2 | 4 | 1 | 0540 | | | 5�40 | 113�5 | 70�2 | 6 | 1 |
| 0260 | | | 2�60 | 77�5 | 33�8 | 4 | 1 | 0550 | | | 5�50 | 113�5 | 71�5 | 6 | 1 |
| 0265 | | | 2�65 | 77�5 | 34�5 | 4 | 1 | 0560 | | | 5�60 | 113�5 | 72�8 | 6 | 1 |
| 0270 | | | 2�70 | 77�5 | 35�1 | 4 | 1 | 0570 | | | 5�70 | 113�5 | 71�8 | 6 | 1 |
| 0275 | | | 2�75 | 79�0 | 35�8 | 4 | 1 | 0580 | | | 5�80 | 113�5 | 73�1 | 6 | 1 |
| 0280 | | | 2�80 | 79�0 | 36�4 | 4 | 1 | 0590 | | | 5�90 | 113�5 | 72�0 | 6 | 1 |
| 0285 | | | 2�85 | 79�0 | 37�1 | 4 | 1 | 0600 | | | 6�00 | 113�5 | 73�2 | 6 | 1 |
