| Technical Data: | |
| Output | 13 kW |
| Connection | 3× 400-480 V, 16 A |
| Tools made of | HM and HSS |
| Tool | 3-32 mm |
| Max� length of the shrink-fit chuck | 535 mm |
| Width × depth × height | 1340 × 962 × 2560 mm (max� Working height) |
| Weight | 550 kg |
Design: - only available in combination with base cabinet - network-compatible and industry 4.0 ready - with 7” touch display and intuitive software - with NG coil - gentle and clean contour-independent cooling of all shrink chucks and shrink collets by air and spray mist without dirt and water residues - temperature monitoring for optimised and safe cooling - no damage at the edges of the cutting tool - incl. 2 precision base holders and 2 precision chuck supports - integrated drawer in base cabinet 24
242714 HAIMER, Power Clamp Sprint i4.0
| Type | 242714 |
| 0001 | + |
Shrink-fit unit
| Technical Data: | |
| Output | 13 kW |
| Connection | 3× 400-480 V, 16 A |
| Tools made of | HM and HSS |
| Tool | 3-32 mm |
| Max� length of the shrink-fit chuck | 535 mm |
| Width × depth × height | 1340 × 914 × 1816 mm |
| Weight | 535 kg (incl� base cabinet) |
Design: - only available in combination with base cabinet - network-compatible and industry 4.0 ready - with 7” touch display and intuitive software - with intelligent NG coil - new TME cooling system with temperature monitoring - integrated contact cooling with five cooling bodies - linear guided cooling bodies with automatic signalling of the rightcooling station - no damage at the edges of the cutting tool - incl. speed cooler and cooling manager - incl. 2 precision base holders and 2 precision chuck supports - integrated drawers in base cabinet
242715 HAIMER, Power Clamp Premium NG
Type 242715 0001 +
Accessories for shrink-fit unit
242708 HAIMER, chuck support for single-position system
242709 HAIMER, chuck support for rotary table, with 3 adapter disks
| Type | 242708 | 242709 | Design | Type | 242708 | 242709 | Design |
| 0030 | | | for SK30 | 1040 | | | for HSK40 |
| 0040 | | | for SK40 | 1050 | | | for HSK50 |
| 0045 | | | for SK45 | 1063 | | | for HSK63 |
| 0050 | | | for SK50 | 1080 | | | for HSK80 |
| 1025 | | | for HSK25 | 1100 | | | for HSK100 |
| 1032 | | | for HSK32 | — | — | — | — |
