Steep Tapers d1 Accessories for collet chucks Design:- concentricity to DIN class 2- DIN 6343 DIN 1856343E - clamping range bridging h9, i.e. only nominal size can be clamped - bore execution up to Ø 8 mm smooth, above with transverse grooves Use: - for bar stock, cut-to-length and pre-worked workpieces - for workpiece clamping (bar or chuck work) in conventional single spindle lathes and CNC lathes directly in the spindle or collet chuck 24 249350 FAHRION, dead length collet, round, 185 E, clamping range 4.0 - 60.0 mm mm 249350 K L F Ammmmmmmm mm 249350 Kmm Lmm Fmm Amm 4,0  84 110 66 73 33,0  84 110 66 73 5,0  84 110 66 73 34,0  84 110 66 73 6,0  84 110 66 73 35,0  84 110 66 73 7,0  84 110 66 73 36,0  84 110 66 73 8,0  84 110 66 73 37,0  84 110 66 73 9,0  84 110 66 73 38,0  84 110 66 73 10,0  84 110 66 73 39,0  84 110 66 73 11,0  84 110 66 73 40,0  84 110 66 73 12,0  84 110 66 73 41,0  84 110 66 73 13,0  84 110 66 73 42,0  84 110 66 73 14,0  84 110 66 73 43,0  84 110 66 73 15,0  84 110 66 73 44,0  84 110 66 73 16,0  84 110 66 73 45,0  84 110 66 73 17,0  84 110 66 73 46,0  84 110 66 73 18,0  84 110 66 73 47,0  84 110 66 73 19,0  84 110 66 73 48,0  84 110 66 73 20,0  84 110 66 73 49,0  84 110 66 73 21,0  84 110 66 73 50,0  84 110 66 73 22,0  84 110 66 73 51,0  84 110 66 73 23,0  84 110 66 73 52,0  84 110 66 73 24,0  84 110 66 73 53,0  84 110 66 73 25,0  84 110 66 73 54,0  84 110 66 73 26,0  84 110 66 73 55,0  84 110 66 73 27,0  84 110 66 73 56,0  84 110 66 73 28,0  84 110 66 73 57,0  84 110 66 73 29,0  84 110 66 73 58,0  84 110 66 73 30,0  84 110 66 73 59,0  84 110 66 73 31,0  84 110 66 73 60,0  84 110 66 73 32,0  84 110 66 73 32,0  84 110 66 73 Accessories for high precision chucks Design: For clamping tools with cylindrical shank with utmost precision in HG chucks l1 241320 HAIMER, collet HG mm 241320 d 1mm l 1mm mm 241320 d 1mm l 1mm mm 241320 d 1mm l 1mm 2,00  14.70 52.5 6,00  14.70 52.5 12,00  17.87 64.2 2,50  14.70 52.5 6,30  14.70 52.5 12,50  17.87 64.2 3,00  14.70 52.5 7,00  14.70 52.5 14,00  17.87 64.2 4,00  14.70 52.5 8,00  14.70 52.5 16,00  26.14 69.7 4,50  14.70 52.5 9,00  14.70 52.5 18,00  26.14 69.7 5,00  14.70 52.5 10,00  17.87 64.2 20,00  26.14 69.7 5,50  14.70 52.5 11,00  17.87 64.2 11,00  17.87 64.2 24/518 www.precitool.de
