Steep Tapers Accessories for collet chucks Design:- concentricity to DIN class 2- DIN 6343 DIN 1736343E - clamping range bridging h9, i.e. only nominal size can be clamped - hole execution up to x 8 mm smooth, above that with transverse grooves Collets with smooth bore available on request Use: - for bar stock, cut-to-length and pre-worked workpieces - for workpiece clamping (bar or chuck work) in conventional single spindle lathes and CNC lathes directly in the spindle or collet chuck 24 249300 FAHRION, dead length collet, round, 173 E, clamping range 3.0 - 42.0 mm 249320 FAHRION, dead length collet, hexagon, 173 E, clamping range 6.0 - 36.0 mm 249340 FAHRION, dead length collet, square, 173 E, clamping range 6.0 - 25.0 mm Xmm 249300 249320 249340 K L F Ammmmmmmm Xmm 249300 249320 249340 K L F Ammmmmmmm 3,0  — — 60 94 48 50 23,0  — — 60 94 48 50 3,5  — — 60 94 48 50 23,5  — — 60 94 48 50 4,0  — — 60 94 48 50 24,0   — 60 94 48 50 4,5  — — 60 94 48 50 24,5  — — 60 94 48 50 5,0  — — 60 94 48 50 25,0  —  60 94 48 50 5,5  — — 60 94 48 50 25,5  — — 60 94 48 50 6,0    60 94 48 50 26,0  — — 60 94 48 50 6,5  — — 60 94 48 50 26,5  — — 60 94 48 50 7,0    60 94 48 50 27,0  — — 60 94 48 50 7,5  — — 60 94 48 50 27,5  — — 60 94 48 50 8,0    60 94 48 50 28,0  — — 60 94 48 50 8,5  — — 60 94 48 50 28,5  — — 60 94 48 50 9,0    60 94 48 50 29,0  — — 60 94 48 50 9,5  — — 60 94 48 50 29,5  — — 60 94 48 50 10,0    60 94 48 50 30,0   — 60 94 48 50 10,5  — — 60 94 48 50 30,5  — — 60 94 48 50 11,0    60 94 48 50 31,0  — — 60 94 48 50 11,5  — — 60 94 48 50 31,5  — — 60 94 48 50 12,0    60 94 48 50 32,0   — 60 94 48 50 12,5  — — 60 94 48 50 32,5  — — 60 94 48 50 13,0    60 94 48 50 33,0  — — 60 94 48 50 13,5  — — 60 94 48 50 33,5  — — 60 94 48 50 14,0    60 94 48 50 34,0  — — 60 94 48 50 14,5  — — 60 94 48 50 34,5  — — 60 94 48 50 15,0   — 60 94 48 50 35,0  — — 60 94 48 50 15,5  — — 60 94 48 50 35,5  — — 60 94 48 50 16,0    60 94 48 50 36,0   — 60 94 48 50 16,5  — — 60 94 48 50 36,5  — — 60 94 48 50 17,0   — 60 94 48 50 37,0  — — 60 94 48 50 17,5  — — 60 94 48 50 37,5  — — 60 94 48 50 18,0  —  60 94 48 50 38,0  — — 60 94 48 50 18,5  — — 60 94 48 50 38,5  — — 60 94 48 50 19,0   — 60 94 48 50 39,0  — — 60 94 48 50 19,5  — — 60 94 48 50 39,5  — — 60 94 48 50 20,0  —  60 94 48 50 40,0  — — 60 94 48 50 20,5  — — 60 94 48 50 40,5  — — 60 94 48 50 21,0  — — 60 94 48 50 41,0  — — 60 94 48 50 21,5  — — 60 94 48 50 41,5  — — 60 94 48 50 22,0    60 94 48 50 42,0  — — 60 94 48 50 22,5  — — 60 94 48 50 — — — — — — — — www.precitool.de 24/517
