- very high clamping force transmission of this maintenance-free worm gear ISO - flat taper angle of the clamping sleeve 26623-1 - holding torque > 350 Nm at 16 mm
Use: For drilling, reaming, tapping etc., finishing and heavy and hard machining, HSC and HPC machining. Clamping of parallel shanks to DIN 1835 A, B and DIN 6535 HB, HA and HE up to Ø 20 mm
Balancing: Standard balanced 15,000 1/min G6.3
Note: Matching accessories see page 24/529 et seq.
24
standard slim long
241117 ALBRECHT, chuck APC, short version, type S
| Taper × A × clamping range mm | 241117 | Clamping range mm | A mm | D1 mm | D2 mm | l1 mm | L² mm | L3 mm |
| C6×80×2-20 | | 2-20 | 80 | 40 | 63 | 18 | 38 | — |
| C6×120×16-32 | | 16-32 | 120 | 63 | — | 83 | — | — |
| C8×90×2-20 | | 2-20 | 90 | 40 | 63 | 18 | 38 | 43 |
| C8×130×16-32 | | 16-32 | 130 | 70 | — | 83 | — | — |
241119 ALBRECHT, chuck APC, medium long version, type D
| Taper × A × clamping range mm | 241119 | Clamping range mm | A mm | D1 mm | D2 mm | l1 mm | L² mm | L3 mm |
| C5×125×2-14 | | 2-14 | 125 | 30 | 50 | 61 | 78 | 93 |
| C6×130×2-20 | | 2-20 | 130 | 40 | 63 | 48 | 68 | — |
| C8×140×2-20 | | 2-20 | 140 | 40 | 64 | 48 | 68 | 93 |
