Steep Tapers Steep taper adapter JIS B 6339 Design: - slim version with axial length adjustment- vibration damping JIS ISO Form6339 B7388-2AD/BHPCHSC G 2,525.000 min-1 - clamping without peripherals, only with an Allen key - concentricity < 0.003 mm - maximum speed 50,000 rpm-1 Note: Intermediate sleeve see 241461 and 241462 on page 24/527. 24 241414 SCHUNK, hydraulic expansion chuck Tendo, short, slim BT/D1mm 241414 D2mm D3mm D4mm Xmm L1mm L²mm L3mm L4mm L5mm L6mm L7mm G Mmin mNmkg 40/06  26 44.5 22 53 90 37 10 43.0 3.6 20.5 63 M5  16 1.4 40/08  28 44.5 24 53 90 37 10 44.5 3.6 20.5 63 M6  23 1.4 40/10  30 44.5 26 49 90 41 10 44.5 3.6 25.5 63 M8   × 1  45 1.4 40/12  32 44.5 28 44 90 46 10 44.5 3.6 30.5 63 M10 × 1  90 1.4 40/16  38 44.5 34 41 90 49 10 47.5 3.6 35.0 63 M12 × 1 185 1.5 40/20  42 44.5 38 39 90 51 10 47.5 3.7 37.8 63 M16 × 1 330 1.5 40/32  63 80.0 60 22 83 61 10 25.5 4.2 47.7 56 M16 × 1 650 2.1 50/12  32 44.5 28 44 90 46 10 34.0 3.6 30.5 52 M10 × 1  90 4.0 50/20  42 44.5 38 39 90 51 10 34.0 3.7 37.8 52 M16 × 1 330 4.0 241416 SCHUNK, hydraulic expansion chuck Tendo, long, slim BT/D1mm 241416 D2mm D3mm D4mm Xmm L1mm L²mm L3mm L4mm L5mm L6mm L7mm G Mmin mNmkg 40/06  26 44.5 22 103 140 37 10 43.0 3.6 20.5 113 M5 16 2.0 40/08  28 44.5 24 103 140 37 10 44.5 3.6 20.5 113 M6 23 2.0 40/10  30 44.5 26  99 140 41 10 44.5 3.6 25.5 113 M8   × 1 45 2.0 40/12  32 44.5 28  94 140 46 10 44.5 3.6 30.5 113 M10 × 1 90 2.0 40/16  38 44.5 34  91 140 49 10 47.5 3.6 35.0 113 M12 × 1 185 2.1 40/20  42 44.5 38  89 140 51 10 47.5 3.7 37.8 113 M16 × 1 330 2.1 50/12  32 44.5 28  94 140 46 10 34.0 3.6 30.5 102 M10 × 1 90 4.6 50/20  42 44.5 38  89 140 51 10 34.0 3.7 37.8 102 M16 × 1 330 4.7 Steep taper adapter JIS B 6339 Design: - concentricity < 0.003 at 2.5 × D- for automatic tool change JIS ISO Form6339 B7388-2ADHSCG 2,5 25.000 min-1 - without length adjustment screw - tool shank quality h6 - optimum tool for light-duty machining; please observe radial forces Note: Matching accessories see page 24/528. 241425 SCHUNK, polygonal toolholder TRIBOS® Mini Type 241425 D1mm D2mm D3mm D5mm L1mm L²mm L4mm L7mm L8mm MminNm mkg 3001  1.0 9 16 11 52 17.5 25 30 22.5 — 0.25 30015  1.5 9 16 11 52 17.5 25 30 22.5 — 0.25 3002  2.0 9 16 11 52 17.5 25 30 22.5 1.0 0.25 3003  3.0 9 16 11 52 17.5 25 30 22.5 1.5 0.25 3004  4.0 9 16 11 52 17.5 25 30 22.5 2.5 0.25 3006  6.0 9 16 11 52 17.5 25 30 22.5 4.5 0.25 www.precitool.de 24/451
