- for highly precise clamping of tools with cylindrical shankJISISOFormG 2,5
with special collets6339 B7388-2AD/B

25.000 min-1 - excellent for high-speed machining, with steep taper, JIS B 6339 BT 40 / BT 50 form ADB - form ADB: Central coolant supply and resealable coolant

ducts at collar - shank tolerance h6

Delivery: - HG chuck with clamping screw - extraction hook

Note: Fitting collets see under 241320 on page 24/518

241310 HAIMER, high-precision chuck, short

l 1

24

BT/Size241310Clamping range mmd1 mml1 mmBT/Size241310Clamping range mmd1 mml1 mm
40/HG012- 8306550/HG0210-143570
40/HG0210-14357050/HG0316-204875
40/HG0316-204875—————
241311 HAIMER, high-precision chuck,long
BT/Size241311Clamping range mmd1 mml1 mmBT/Size241311Clamping range mmd1 mml1 mm
40/HG012- 83010040/HG0316-2048100
40/HG0210-143510050/HG0210-1435100
241312 HAIMER, high-precision chuck,overlong
BT/Size241312Clamping range mmd1 mml1 mmBT/Size241312Clamping range mmd1 mml1 mm
50/HG01 Steep ta per adap2-8 ter JIS B 63330 916050/HG0210-1435160
Use: For holding tools iil t DIN 63with morse taper 3 ith t tshank with tang ac JIS B 6339 BT 4cording to DIN 2 / 50 f AD28-1 formB,JIS 6339 B ISO 7388-2Form AD G 6,3 8.000 min-1

l 1

241058 HAIMER, intermediate sleeve, short

241060 PRECITOOL, intermediate sleeve, short

BT × MT241058241060d3 mml1 mmLocking threadBT × MT241058241060d3 mml1 mmLocking thread
40×12550M1650×2—3260M24
40×23250M1650×3—4065M24
40×34070M1650×4—4895M24
40×44895M16——————
