- cooling through aligned cooling nozzle and high-pressure cooling nozzle 69893 12164-3 26623-1
- driving grooves at HST to ICTM standard - clamp holder for external machining can also be used for internal machining considering the D1 min. Note:
L = left R = right HST T PSC *Version HP ready - info see page 23/367.
D1 min. D1 min. f
f 93° 93° A
A
237017 HST T, 93°/55° SDUC L/R 23
237117 PSC, 93°/55° SDUC L/R
237017 237117 f D1 min�
| Type | 237017 | 237117 | A | A | taper | Indexable insert | ||
| mm | mm | |||||||
| mm | mm | |||||||
| 4011R | | | 55 | 50 | 40 | 27 | 50 | DC���11 T3��� |
| 4011L | | | 55 | 50 | 40 | 27 | 50 | DC���11 T3��� |
| 5011R | — | | — | 60 | 50 | 35 | 65 | DC���11 T3��� |
| 5011L | — | | — | 60 | 50 | 35 | 65 | 237117 237017 DC���11 T3��� |
| 6311R | | | 70 | 65 | 63 | 45 | 80 | DC���11 T3��� |
| 6311L | | | 70 | 65 | 63 | 45 | 80 | DC���11 T3��� |
237019 HST T, 93°/55° PDUN L/R
237119 PSC, 93°/55° PDUN L/R
237019 237119 f D1 min�
| Type | 237019 | 237119 | A | A | taper | Indexable insert | ||
| mm | mm | |||||||
| mm | mm | |||||||
| 4015R | | | 55 | 50 | 40 | 27 | 50 | DN���15 06��� |
| 4015L | | | 55 | 50 | 40 | 27 | 50 | DN���15 06��� |
| 5015R | — | | — | 60 | 50 | 35 | 65 | DN���15 06���* |
| 5015L | — | | — | 60 | 50 | 35 | 65 | 237119 237019 DN���15 06���* |
| 6325R | | | 70* | 65* | 63 | 45 | 80 | DN���15 06��� |
| 6325L | | | 70* | 65* | 63 | 45 | 80 | DN���15 06��� |
Spare part for clamp mounting / boring bars
| For 237017 | and 237117 | 1 | ||
| Figure no. | Spare part | Design | Item no� | |
| a | TORX®key | T15 | 505450 T15 | |
| b For 237019 | TORX®screw and 237119 | M4 × 9 | 237272 0409 | 2 3 7 |
| Figure no. | Spare part | Design | Item no� | 8 |
| c | Intermediate layer | for DN��1504��� | 238073 1504 | |
| c | Intermediate layer | for DN��1506��� | 238073 1506 | |
| g | Clamping screw | for toggle clamp | 238077 0017 | |
| h | Toggle lever | for DN��1506��� | 238078 1504 | |
