- cooling through aligned cooling nozzle and high-pressure cooling nozzle 69893 12164-3 26623-1
- driving grooves at HST to ICTM standard - clamp holder for external machining can also be used for internal machining considering the D1 min. Note:
L = left R = right *Version HP ready - info see page 23/411
| 37020 37120 Type | HST PSC, 237020 | T, 55°/93 55°/93° 237120 | ° SDJ SDJC 237020 A mm | C L/R L/R 237120 A mm | taper | f mm | D1 min� mm | Indexable insert D1 min. f | HST T 93° A D1 min. | 93° A f PSC |
| 4011R | | | 55 | 50 | 40 | 27 | 50 | DC���11 T3��� | ||
| 4011L | | | 55 | 50 | 40 | 27 | 50 | DC���11 T3��� | ||
| 5011R | — | | — | 60 | 50 | 35 | 60 | DC���11 T3��� | ||
| 6311R | | | 70 | 65 | 63 | 45 | 80 | DC���11 T3��� | 237020 | 237120 |
| 6311L | | | 70 | 65 | 63 | 45 | 80 | DC���11 T3��� |
23
237022 HST T, 55°/93° PDJN L/R
237122 PSC, 55°/93° PDJN L/R
| Type | 237022 | 237122 | 237022 A mm | 237122 A mm | taper | f mm | Indexable insert | ||
| 4015R | | | 55 | 50 | 40 | 27 | DN���15 06��� | ||
| 4015L | | | 55 | 50 | 40 | 27 | DN���15 06��� | ||
| 5015R | — | | — | 60 | 50 | 35 | DN���15 06��� | ||
| 5015L | — | | — | 60 | 50 | 35 | DN���15 06��� | ||
| 6325R | | | 70 | 65 | 63 | 45 | DN���15 06��� | 237022 | 237122 |
| 6325L | | | 70 | 65 | 63 | 45 | DN���15 06��� |
Spare part for clamp mounting / boring bars
| or 23702 | 0 and 237120 | 1 | |||
| Figure no. | Spare part | Design | Item no� | ||
| a | TORX®key | T15 | 505450 T15 | | |
| b or 23702 | TORX®screw 2 and 237122 | M4 × 9 | 237272 0409 | | 2 3 7 |
| Figure no. | Spare part | Design | Item no� | 8 | |
| c | Intermediate layer | for DN��1504��� | 238073 1504 | | |
| c | Intermediate layer | for DN��1506��� | 238073 1506 | | |
| g | Clamping screw | for toggle clamp | 238077 0017 | | |
| h | Toggle lever | for DN��1506��� | 238078 1504 | |
