| - ISO clamp mounting with square shank | DIN | ISO |
| - adjustable cooling nozzle with internal thread | 69893 | 12164-3 |
- driving grooves at HSK to ICTM standard Note: L = left R = right
D L 237001 HST T, axial, single A
B Square A L
Type 237001 HST T
| mm | mm | mm | mm | mm | |||
| 4020R | | 40 | 30 | 20 × 20 | 80 | 45 | 80 |
| 4020L | | 40 | 30 | 20 × 20 | 80 | 45 | 80 |
| 6320R | | 63 | 30 | 20 × 20 | 90 | 45 | 80 |
| 6320L | | 63 | 30 | 20 × 20 | 90 | 45 | 80 |
| 6325R | | 63 | 40 | 25 × 25 | 100 | 58 | 102 |
| 23 6325L | | 63 | 40 | 25 × 25 | 100 | 58 | 102 |
D DIN ISO 69893 12164-3
237002 HST T, axial, double
| Type | 237002 | HST T |
| 4020R | | 40 |
| 6320R | | 63 |
| 6325R | | 63 |
DIN ISO 69893 12164-3
L A
| B | Square | A | L | |
| mm | mm | mm | mm | mm |
| 30 | 20 × 20 | 80 | 45 | 90 |
| 30 | 20 × 20 | 90 | 45 | 90 |
| 40 | 25 × 25 | 100 | 58 | 102 |
D
237003 HST T, axial, 3-fold
| Type | 237003 | HST T |
| 6320R | | 63 |
| 6325R | | 63 |
DIN ISO 69893 12164-3
L A
| B | Square | A | L | |
| mm | mm | mm | mm | mm |
| 30 | 20 × 20 | 90 | 58 | 90 |
| 40 | 25 × 25 | 100 | 58 | 102 |
D 25 237004 HST T, radial A
| Type | 237004 | B | Square | A | | |
| HST T | ||||||
| mm | mm | mm | mm | |||
| 4020 | | 40 | 30 | 20 × 20 | 75 | 80 |
| 6320 | | 63 | 30 | 20 × 20 | 90 | 80 |
| 6325 | | 63 | 40 | 25 × 25 | 90 | 102 |
DIN ISO A
69893 12164-3
f HST T L 237005 HST T, diagonal, 45° D
| Type | 237005 | f | Square | A | | |
| HST T | ||||||
| mm | mm | mm | mm | |||
| 6320L | | 63 | 5 | 20 × 20 | 100 | 80 |
| 6320R | | 63 | 5 | 20 × 20 | 100 | 80 |
| 6325L | | 63 | 5 | 25 × 25 | 100 | 102 |
| 6325R | | 63 | 5 | 25 × 25 | 100 | 102 |
