Multi-tooth cutter VHM GRP / CRP
Plastics Factory Type
Cat. no. VHM Plastics
| N/mm2 | standard | W | |
| 6535 HA |
179502 180° Centre cut shank
GRP 179504 vc = m/min. 179502 Solid Carbide End Mills
100-180 100-200 179504 17
Versions 179502 and 179504: Version 179512:
| - 180° point angle | drawing cut - 179502 - with drill point |
| - multi-tooth | - 135° point angle |
| - staggered toothing | (h10) - multi-tooth |
| - right hand spiral | 90° - staggered toothing |
| - right hand spiral | |
| Use: | |
| - medium toothing for the treatment | Use: |
| of GRP / CRP | - medium toothing for the |
| - drawing cut (179502) | pushing cut - 179504 treatment of GRP / CRP |
| - pushing cut (179504) | - pushing cut |
| - mainly for roughing thin materials | (h10) - mainly for roughing thin materials |
90° 179502 PRECITOOL, drawing cut 179504 PRECITOOL, pushing cut
| d1 mm | 179502 | 179504 | l1 mm | l2 mm | d2 mm | GRP f mm/U | CRP f mm/U |
| 4,00 | | | 50 | 16 | 4 | 0�100 - 0�400 | 0�200 - 0�600 |
| 5,00 | | | 50 | 16 | 5 | 0�100 - 0�400 | 0�200 - 0�600 |
| 6,00 | | | 60 | 19 | 6 | 0�100 - 0�400 | 0�200 - 0�600 |
| 8,00 | | — | 63 | 25 | 8 | 0�100 - 0�400 | 0�200 - 0�600 |
| 10,00 | | | 72 | 25 | 10 | 0�100 - 0�400 | 0�200 - 0�600 |
| 12,00 | | — | 83 | 32 | 12 | 0�100 - 0�400 | 0�200 - 0�600 |
| 16,00 | | — | 92 | 36 | 16 | 0�100 - 0�400 | 0�200 - 0�600 |
| 20,00 | | — | 104 | 45 | 20 | 0�100 - 0�400 | 0�200 - 0�600 |
End mill VHM GRP / CRP
Plastics Factory Teeth
Cat. no. VHM Blade form
N/mm2 standard 8 chamfer
179550 coated Centre cut
179552 GRP 179554 Plastics 6535 HA vc = m/min. shank
179550 120-280
179552 120-250 100-280
179554 120-280 Version 179550: Neutral cut - 179550 - straight serrated, neutral cut - diamond coated (h10)
- not face cutting 45°
Use: For roughing and finishing of GRP / CRP in one operation.
Versions 179552 and 179554: Drawing cut - 179552 - 8° right hand spiral, drawing cut (179552) - 8° left hand spiral, pushing cut (179554)
- diamond coated 45° (h10)
- face cutting Use: For roughing and finishing of GRP / CRP in one operation. Pushing cut - 179554
45° (h10)
179550 PRECITOOL, straight, with chamfer, diamond
179552 PRECITOOL, drawing cut, with chamfer, diamond
179554 PRECITOOL, pushing cut, with chamfer, diamond
| d | F | l | l | d | CRP GRP | |||||
| 1 | 179550 | 179552 | 179554 | 1 | 2 | 2 | ||||
| mm | mm | mm | mm | mm | f mm/U f mm/U | |||||
| 4,00 | | | | 0�080 | 60 | 16 | 6 | 0�200 - 0�500 | 0�300 - 0�600 | |
| 5,00 | | | | 0�100 | 60 | 18 | 6 | 0�200 - 0�500 | 0�300 - 0�600 | |
| 6,00 | | | | 0�120 | 60 | 20 | 6 | 0�200 - 0�500 | 0�300 - 0�600 | |
| 8,00 | | | | 0�160 | 63 | 22 | 8 | 0�200 - 0�500 | 0�300 - 0�600 | |
| 10,00 | | | | 0�200 | 72 | 32 | 10 | 0�200 - 0�500 | 0�300 - 0�600 | |
| 12,00 | | | | 0�200 | 83 | 32 | 12 | 0�200 - 0�500 | 0�300 - 0�600 | |
| 16,00 | | | | 0�200 | 92 | 36 | 16 | 0�200 - 0�500 | 0�300 - 0�600 | |
| 20,00 | | | | 0�200 | 104 | 45 | 20 | 0�200 - 0�500 | 0�300 - 0�600 |
