Torus cutter VHM HRC
| H | Tolerance | Teeth | Blade form | |||||||
| HRC | Diameter | Edge- | Shank- | standard | 4 | 30° | ||||
| range | d | (g7) | d | (h5) | radius | Twist |
| 179070 | < 62 | coated | Centre cut | ||||
| 1 | 2 | ||||||
| vc = m/min. | H | ||||||
| 179070 200-400 | 6535 HA |
Solid Carbide End Mills shank HPM HSM
17
179070 HighQ, short/medium/long, with corner radius, TiAlN
62 HRC (g7)
| d × l × r × l | l | l | l | d | to fz y a | |||
| 1 | 4 | 179070 | 1 | 2 | 4 | 2 | ||
| mm | mm | mm | mm | mm | up (°) mm mm/tooth | |||
| 2,00×6×0,15×45 | | 45 | 3 | 6 | 4 0�10 7 | 0�030 - 0�075 | ||
| 4,00×18×0,3×60 | | 60 | 6 | 18 | 6 0�10 6 | 0�050 - 0�100 | ||
| 6,00×25×1,0×65 | | 65 | 6 | 25 | 6 0�20 — | 0�065 - 0�125 | ||
| 6,00×35×0,5×79 | | 79 | 6 | 35 | 6 0�20 — | 0�065 - 0�125 | ||
| 8,00×25×0,5×65 | | 65 | 8 | 25 | 8 0�30 — | 0�080 - 0�130 | ||
| 8,00×25×0,5×79 | | 79 | 8 | 35 | 8 0�30 — | 0�080 - 0�130 | ||
| 10,00×35×0,5×79 | | 79 10 | 35 | 10 0�30 — | 0�085 - 0�135 | |||
| 10,00×35×2,0×79 | | 79 10 | 35 | 10 0�30 — | R 0�085 - 0�135 | |||
| 10,00×55×1,0×100 | | 100 10 | 55 | 10 0�30 — | 0�085 - 0�135 | |||
| Torus cutter VHM HRC | ||||||||
| H | Tolerance | Blade form Teeth | ||||||
| Cat. no. | corner Factory VHM | |||||||
| HRC | Diameter | Edge- | 45° 6-8 standard Shank- | |||||
| range | 6535 HA Twist radius | |||||||
| 179086 | < 62 | d | (g7) | shank coated (h5) d |
1 2 vc = m/min. H 179086 100-200 HPM HSM
short
62 HRC
to (g7)
up
179086 HighQ, short, with corner radius, TiAIN
| d × r | 179086 | l | l | d | y | fz | |
| mm1 | mm1 | mm2 | mm2 | (°) Z | mm/tooth | ||
| 4,00×0,3 | | 65 | 10 | 6 | 15 6 | 0�030 - 0�045 | |
| 6,00×0,5 | | 65 | 20 | 6 | — 6 | 0�045 - 0�065 | |
| 8,00×0,5 | | 65 | 20 | 8 | — 6 | 0�060 - 0�080 | |
| 12,00×0,5 | 78 | 25 | 12 | — 6 | R 0�085 - 0�110 |
Torus cutter VHM HRC
H Tolerance Teeth Blade form
Cat. no. VHM Factory corner
HRC Diameter Edge- Shank- standard 6-8 45°
range radius Twist 6535 HA
| 179088 | < 70 | d | (g7) | d | (h5) | coated | shank | |
| 1 | 2 | |||||||
| vc = m/min. | H | |||||||
| 179088 | 80-150 |
short HPM HSM
179088 HighQ, short, with corner radius, TiAIN 70 HRC
to (g7)
up
| d × r | l | l | l | d | a | y | fz | ||
| 1 | 179088 | 1 | 2 | 4 | 2 | ||||
| mm | mm | mm | mm | mm | mm | (°) Z | mm/tooth | ||
| 3,00×0,3 | | 65 | 8 | 15 | 6 | 0�05 15 6 | 0�020 - 0�035 | ||
| 4,00×0,3 | | 65 | 10 | 16 | 6 | 0�10 15 6 | 0�030 - 0�045 | ||
| 5,00×0,5 | | 65 | 12 | 18 | 6 | 0�15 15 6 | 0�030 - 0�055 | ||
| 6,00×0,5 | | 65 | 14 | 20 | 6 | 0�20 — 6 | 0�045 - 0�065 | ||
| 8,00×0,5 | | 70 | 18 | 25 | 8 | 0�30 — 6 | 0�060 - 0�080 | ||
| 10,00×0,5 | | 79 | 22 | 30 | 10 | 0�30 — 6 | 0�070 - 0�095 | ||
| 12,00×0,5 | 79 | 26 | 35 | 12 | 0�30 — 6 | R 0�085 - 0�110 |
