Solid Carbide End Mills Quadrant cutter VHM Universal Cat. no. PN/mm2 HHRC MN/mm2 KHB SN/mm2 NN/mm2 VHM Factory Type TeethstandardN4 6535 HB 178810 coated shank < 1200 < 60 < 850 < 350 Titanium <1200 Alu >600 Brass < 600 178815 vc = m/min. UNI 178810 30-90 55-75 20-60 40-80 20-40 100-450 85-190 178815 35-100 65-90 35-70 45-95 25-45 120-500 17 178810 PRECITOOL 178815 PRECITOOL, ALCRONA rmm 178810 178815 l1 d1 d2mmmmmm fzmm/tooth 0,50   70 7 8 0.010 - 0.050 1,00   70 6 8 0.010 - 0.050 1,50   75 7 10 0.010 - 0.050 2,00   75 6 10 0.010 - 0.050 2,50   75 7 12 0.010 - 0.050 178810 3,00   75 6 12 0.010 - 0.050 3,50   80 10 16 0.010 - 0.050 4,00   80 8 16 0.010 - 0.050 4,50   80 7 16 0.010 - 0.050 5,00   80 10 20 0.010 - 0.050 6,00   80 8 20 0.010 - 0.050 178815 Deburring cutter VHM Universal Cat. no. PN/mm2 HHRC MN/mm2 KHB SN/mm2 NN/mm2 VHM Factory Type TeethstandardN3-46535 HA 178850 < 1200 < 60 < 850 >350 Titanium <1200 Alu < 600 Brass < 600 coated shank overlong vc = m/min. 178850 45-100 65-90 25-70 45-95 25-45 120-500 85-190 UNI Design: - angle 45° Use: For forward and reverse deburring. 3 178850 PRECITOOL, extra long, ALCRONA d1mm 178850 l1mm l2mm l3mm d3mm d2mm Z fzmm/tooth 2,00  100 1.4 8 1.2 6 3 0.010 - 0.050 3,00  100 2.0 8 2.0 6 4 0.010 - 0.050 4,00  100 3.0 10 2.0 6 4 0.010 - 0.050 6,00  100 4.0 15 4.0 6 4 0.010 - 0.050 8,00  100 3.2 — — 6 4 0.010 - 0.050 10,00  100 4.3 — — 6 4 0.020 - 0.060 12,00  100 5.0 — — 6 4 0.030 - 0.070 16,00  100 8.0 — — 10 4 0.035 - 0.080 Deburring cutter VHM Universal Cat. no. PN/mm2 HHRC MN/mm2 KHB SN/mm2 NN/mm2 VHM Factory Type TeethstandardN46535 HA 178860 < 1200 < 60 < 850 >350 Titanium <1200 Alu < 600 Brass < 600 coated shank overlong vc = m/min. 178860 35-100 65-90 25-70 45-70 25-45 120-500 85-190 UNI Design: - shank section extra long - head section double ground - with quadrant profile Use:For bidirectional deburring of edges and R contours. 178860 PRECITOOL, extra long, TiAIN rmm 178860 Max.  d1mm smallest  d1 l1 d2mmmmmm fzmm/tooth 0,20  8 7.6 100 6 0.050 - 0.010 0,30  8 7.4 100 6 0.050 - 0.010 0,50  8 7.0 100 6 0.050 - 0.010 1,00  10 8.0 100 6 0.060 - 0.020 1,50  10 7.0 100 6 0.060 - 0.020 17/276 www.precitool.de
