Ball cutter VHM HRC
H Tolerance Teeth
| HRC | Diameter | Edge- | Shank- | standard | 2 | ball | 30° | |||
| range | d | (g7) | d (h5) | Twist |
| 178277 | < 62 | coated | Centre cut | ||||
| 1 | 2 | ||||||
| vc = m/min. | H | ||||||
| 178277 200-400 | 6535 HA |
| Solid Carbide End Mills | shank | HPM | HSM | ||
| 17 | |||||
| 178277 HighQ, short/medium, TiAIN |
| d × l | r | l | l | l | d | a | y | fz | |
| 1 | 1 178277 | 1 | 2 | 4 | 2 | ||||
| mm | mm | mm | mm | mm | mm | mm | (°) | mm/Zahn | |
| 1,00×64 | | 0�50 | 65 | 2 | 4 | 6 | 0�05 | 7 | 0�020 - 0�040 |
| 1,50×64 | | 0�75 | 65 | 2 | 4 | 6 | 0�05 | 7 | (g7) 62 HRC 0�020 - 0�040 |
| 2,00×64 | | 1�00 | 65 | 3 | 5 | 6 | 0�05 | 6 | to 0�030 - 0�075 |
| up | |||||||||
| 2,00×78 | | 1�00 | 79 | 3 | 15 | 6 | 0�05 | 5 | 0�030 - 0�075 |
| 3,00×64 | | 1�50 | 65 | 4 | 7 | 6 | 0�05 | 5 | 0�040 - 0�090 |
| 4,00×64 | | 2�00 | 65 | 5 | 8 | 6 | 0�10 | 4 | 0�050 - 0�100 |
| 4,00×78 | | 2�00 | 79 | 5 | 15 | 6 | 0�10 | 3 | 0�050 - 0�100 |
| 5,00×64 | | 2�50 | 65 | 5 | 10 | 6 | 0�15 | 3 | 0�060 - 0�120 |
| 5,00×78 | | 2�50 | 79 | 5 | 20 | 6 | 0�15 | 2 | 0�060 - 0�120 |
| 6,00×64 | | 3�00 | 65 | 6 | 25 | 6 | 0�20 | — 0�065 - 0�125 | |
| 6,00×78 | | 3�00 | 79 | 6 | 35 | 6 | 0�20 | — 0�065 - 0�125 | |
| 8,00×64 | | 4�00 | 65 | 8 | 25 | 8 | 0�30 | — 0�080 - 0�130 | |
| Ball cutter VHM Universal | |||||||||
| P | H | M | K | Teeth Type DIN |
Cat. no. VHM Blade form
| N/mm2 | HRC | N/mm2 | HB | 6527 | 30° ball 4 N | ||
| 178415 | < 1200 | < 60 | < 850 | <300 | Twist | ||
| coated | |||||||
| vc = m/min. | UNI | ||||||
| 178415 115-240 | 50-60 | 65-105 145-240 | 6535 HB | ||||
| Centre cut shank | long | ||||||
| 178415 PRECITOOL, long, ALCRONA |
| d | r | l | l | d | fz | ||
| 1 | 178415 | 1 | 2 | 2 | |||
| mm | mm | mm | mm | mm | mm/tooth | ||
| 2,00 | | 1�0 | 57 | 6 | 6 | 0�005 - 0�010 | |
| 3,00 | | 1�5 | 57 | 8 | 6 | 0�010 - 0�016 | |
| 4,00 | | 2�0 | 57 | 11 | 6 | 0�018 - 0�024 | |
| 5,00 | | 2�5 | 57 | 13 | 6 | 0�020 - 0�026 | |
| 6,00 | 3�0 | 57 | 13 | 6 | (h9) 0�024 - 0�029 | ||
| 8,00 | | 4�0 | 63 | 19 | 8 | 0�032 - 0�042 | |
| 10,00 | | 5�0 | 72 | 22 | 10 | 0�038 - 0�053 | |
| 12,00 | | 6�0 | 83 | 26 | 12 | 0�046 - 0�063 | |
| 14,00 | | 7�0 | 83 | 26 | 14 | 0�046 - 0�063 | |
| 16,00 | | 8�0 | 92 | 32 | 16 | 0�054 - 0�079 | |
| 18,00 | | 9�0 | 92 | 32 | 18 | 0�054 - 0�079 | |
| 20,00 | | 10�0 | 104 | 38 | 20 | 0�066 - 0�097 | |
| P | H M | K | Teeth Type Factory |
Cat. no. VHM Blade form
| N/mm2 | HRC | N/mm2 | HB | standard | 30° ball 4 N | ||
| 178430 | Twist | ||||||
| coated | |||||||
| < 1200 | < 60 | < 850 | <300 | ||||
| 178435 | UNI | ||||||
| vc = m/min. | 6535 HB | ||||||
| 178430 | 50-110 | 20-30 | 30-45 | 76-115 | Centre cut shank | overlong | |
| 178435 | 90-180 | 35-45 | 50-75 | 105-180 | |||
| 178430 PRECITOOL, extra long | |||||||
| 178435 PRECITOOL, extra long, ALCRONA |
| d × l | r | l | d | fz | |||
| 1 | 2 178430 | 178435 | 1 | 2 | |||
| mm | mm | mm | mm | mm/tooth | |||
| 3,00×20 | | | 1�5 | 57 | 6 | 0�003 - 0�010 | |
| 4,00×20 | | | 2�0 | 57 | 6 | 0�006 - 0�018 | |
| 5,00×30 | | | 2�5 | 75 | 6 | (h9) 0�007 - 0�020 | |
| 6,00×30 | | | 3�0 | 75 | 6 | 0�009 - 0�024 | |
| 6,00×40 | | | 3�0 | 100 | 6 | 0�009 - 0�024 | |
| 8,00×30 | | | 4�0 | 75 | 8 | 0�014 - 0�032 | |
| 8,00×40 | | | 4�0 | 100 | 8 | 0�014 - 0�032 | |
| 178430 | |||||||
| 10,00×30 | | | 5�0 | 75 | 10 | 0�018 - 0�038 | |
| 10,00×40 | | | 5�0 | 100 | 10 | 0�018 - 0�038 | |
| 12,00×45 | | | 6�0 | 100 | 12 | 0�022 - 0�046 | |
| 12,00×65 | 6�0 | 150 | 12 | (h9) 0�022 - 0�046 | |||
| 14,00×45 | | — | 7�0 | 100 | 14 | 0�022 - 0�046 | |
| 14,00×65 | | — | 7�0 | 150 | 14 | 0�022 - 0�046 | |
| 16,00×45 | | | 8�0 | 100 | 16 | 0�027 - 0�054 | |
| 16,00×65 | | | 8�0 | 150 | 16 | 178435 0�027 - 0�054 | |
| 16,00×90 | | | 8�0 | 150 | 16 | 0�027 - 0�054 |
