End mill VHM Inox, with relieved shank
| M | S | Teeth | ||
| N/mm2 | N/mm2 | standard | 4 | |
| 6535 HB |
175588 < 850 Titanium, titanium alloys coated Centre cut shank
vc = m/min. M S
| 175588 | 80-120 | 60-70 | ||
| Shank | Cutting data |
Solid Carbide End Mills long relieved
Design: 17 - unequal division - long version - shank with toric cut
- cutting points with protective chamfer - Alnova coated
Use: - for Inox and titanium materials - for roughing and finishing - for large cutting depths - extremely high cutting performance - very high running smoothness 3 - very quiet running
(h10)
90°
4
175588 PRECITOOL-GP, long, with protective chamfer, sharp-edged, ALNOVA
| d1 mm | 175588 | Protective chamfe mm | r l1 mm | l2 mm | l4 mm | d3 mm | d2 mm | fz mm/tooth | d1 mm | 175588 | Protective chamfer mm | l1 mm | l2 mm | l4 mm | d3 mm | d2 mm | fz mm/tooth |
| 3,00 | | 0�03 | 57 | 8 | 12 | 2�8 | 6 | 0�010 - 0�015 | 10,00 | | 0�10 | 72 | 22 | 32 | 9�5 | 10 | 0�040 - 0�050 |
| 4,00 | | 0�04 | 57 | 11 | 15 | 3�8 | 6 | 0�014 - 0�020 | 12,00 | | 0�12 | 83 | 26 | 38 | 11�5 | 12 | 0�045 - 0�055 |
| 5,00 | | 0�05 | 57 | 13 | 17 | 4�8 | 6 | 0�018 - 0�024 | 14,00 | | 0�14 | 83 | 26 | 42 | 13�5 | 14 | 0�050 - 0�060 |
| 6,00 | | 0�06 | 57 | 13 | 21 | 5�5 | 6 | 0�020 - 0�028 | 16,00 | | 0�15 | 92 | 32 | 44 | 15�5 | 16 | 0�070 - 0�080 |
| 8,00 | | 0�08 | 63 | 19 | 27 | 7�5 | 8 | 0�030 - 0�038 | 20,00 | | 0�15 | 104 | 38 | 54 | 19�5 | 20 | 0�070 - 0�090 |
End mill VHM Alu, with relieved shank
N Design:
Cat. no. - lapped Factory Type Teeth Blade form
N/mm2 VHM chamfer 45°
| - zirconium nitride coating | standard | W | 4 | ||||
| Twist | |||||||
| 175580 | coated | ||||||
| Alu < 450 Al alloy < 600 | - shank relieved |
| 175582 | - with chamfer | N | |||
| vc = m/min. | |||||
| 6535 HA | Shank |
175580 Centre cut shank long overlong relieved
370-450 145-220 175582
175580 HighQ, long, with chamfer, ZrN
| d | F | l | l | l | d | d | fz | |
| 1 | 175580 | 1 | 2 | 4 | 3 | 2 | ||
| mm | mm | mm | mm | mm | mm | mm | mm/tooth | |
| 3,00 | | 0�10 | 57 | 8 | 12 | 2�8 | 6 | 0�010 - 0�015 |
| 4,00 | | 0�10 | 57 | 11 | 18 | 3�8 | 6 | 0�018 - 0�023 |
| 5,00 | 0�10 | 57 | 13 | 18 | 4�8 | 6 | (h10) 0�020 - 0�025 |
- 45°
| 6,00 | | 0�20 | 57 | 13 | 18 | 5�8 | 6 | 0�025 - 0�031 |
| 8,00 | | 0�20 | 63 | 21 | 25 | 7�8 | 8 | 0�032 - 0�042 |
| 10,00 | | 0�20 | 72 | 22 | 30 | 9�7 | 10 | 0�039 - 0�050 |
| 12,00 | | 0�20 | 83 | 26 | 36 | 11�7 | 12 | 0�048 - 0�059 |
| 16,00 | | 0�20 | 92 | 36 | 42 | 15�7 | 16 | 0�058 - 0�071 |
| 20,00 | | 0�20 | 104 | 41 | 52 | 19�5 | 20 | 0�073 - 0�090 |
175582 HighQ, extra long, with chamfer, ZrN
| d | F | l | l | l | d | d | fz | |||
| 1 | 175582 | 1 | 2 | 4 | 3 | 2 | ||||
| mm | mm | mm | mm | mm | mm | mm | mm/tooth | |||
| 6,00 | 0�20 | 80 | 13 | 42 | 5�8 | 6 | 0�025 - 0�031 | (h10) |
- 45°
16,00 0�20 150 36 100 15�7 16 0�058 - 0�071
