| End | mill VHM In | Design: ox | Use: | de | ||||
| 175584 | M N/mm2 S N/mm2 Titan, Titan- legierungen | - unequal division - short version - cutting edges with | - for In - for r - extre | VHM coated Factory standard ox and titanium materials oughing and finishing mely high cutting performance | Teeth 4 | Blade form chamfer | Centre cut | Carbi ills |
| vc = m/min. | a 45° chamfer - Alnova coated | - very - very | 6535 HB M high running smoothness soft cut | S | lid d M | |||
| 175584 | 80-120 60-70 | shank short | Cutting data | So En | ||||
| 175584 | PRECITOOL-G | P, short, Vplus w | ith cha | mfer, steel | 17 | |||
| d1 mm | 175584 F mm | l1 mm l2 mm | d2 mm | fz mm/tooth | ||||
| 3,00 | 0�13 | 54 6 | 6 | 0�010 - 0�015 | ||||
| 4,00 | 0�18 | 54 8 | 6 | 0�014 - 0�020 | ||||
| 5,00 | 0�20 | 54 9 | 6 | 0�018 - 0�024 | ||||
| 6,00 | 0�20 | 54 10 | 6 | 0�020 - 0�028 | ||||
| 7,00 | 0�20 | 58 12 | 8 | 0�020 - 0�028 | ||||
| 8,00 | 0�20 | 58 12 | 8 | 0�030 - 0�038 | ||||
| 9,00 | 0�30 | 66 14 | 10 | (h10) 0�030 - 0�038 | ||||
| 10,00 | 0�30 | 66 14 | 10 | 45° 0�040 - 0�050 | ||||
| 11,00 | 0�30 | 73 16 | 12 | 0�040 - 0�050 | ||||
| 12,00 | 0�30 | 73 16 | 12 | 0�045 - 0�055 | ||||
| 14,00 | 0�30 | 75 18 | 14 | 0�050 - 0�060 | ||||
| 16,00 | 0�40 | 82 22 | 16 | 0�070 - 0�080 | ||||
| 18,00 | 0�40 | 84 24 | 18 | 0�070 - 0�080 | ||||
| 20,00 | 0�50 | 92 26 | 20 | 0�070 - 0�090 | ||||
| M S | Design: | Use: | ||||||
| N/mm2 N/mm2 | - unequal division | - for In | VHM Factory ox and titanium materials | Teeth | ||||
| 175585 | Titan, Titan- | - short version | - for r | coated standard oughing and finishing | 4 | Centre cut 6535 HB shank | ||
| legierungen vc = m/min. | - cutting points with protective chamfer Al td | - extre - very | M S mely high cutting performance high running smoothness ft t | |||||
| 175585 | 80-120 60-70 | - nova coae | - very | so cu | Ctti dt | |||
| short | ung aa | |||||||
| 175585 | PRECITOOL-G sharp-edged, | P, short, with pro ALNOVA | tectiv | e chamfer, | ||||
| d1 | 175585 Protective | chamfer l1 l2 | d2 | fz | ||||
| mm | m | m mm mm | mm | mm/tooth | ||||
| 3,00 | 0�0 | 3 54 6 | 6 | 0�010 - 0�015 | ||||
| 4,00 | 0�0 | 4 54 8 | 6 | 0�014 - 0�020 | ||||
| 5,00 | 0�0 | 5 54 9 | 6 | 0�018 - 0�024 | ||||
| 6,00 | 0�0 | 6 54 10 | 6 | 0�020 - 0�028 | ||||
| 8,00 | 0�0 | 8 58 12 | 8 | 0�030 - 0�038 | ||||
| 10,00 | 0�1 | 0 66 14 | 10 | 0�040 - 0�050 | ||||
| 12,00 | 0�1 | 2 73 16 | 12 | ° (h10) 0�045 - 0�055 | ||||
| 14,00 | 0�1 | 4 75 18 | 14 | 90 0�050 - 0�060 | ||||
| 16,00 | 0�1 | 5 82 22 | 16 | 0�070 - 0�080 | ||||
| 20,00 | 0�1 | 5 92 26 | 20 | 0�070 - 0�090 |
End mill VHM Inox, with relieved shank
M S Design: Use:
Cat. no. - unequal division - for Inox and titanium materials Factory Teeth Blade form
N/mm2 N/mm2 VHM chamfer
- long version - for roughing and finishing standard 4
Titanium, coated Centre cut
| 175587 | < 850 | - shank with toric cut | - for large cutting depths | |
| titanium alloys | ||||
| - cutting edges with | - extremely high cutting performance | S M | ||
| vc = m/min. | a 45° chamfer | - very high running smoothness | ||
| Shank 6535 HB | ||||
| 175587 | 80-120 | 60-70 - Alnova coated | - very soft cut | long shank |
relieved
SET 4 pieces Cutting data
3 45° (h10)
4
175587 PRECITOOL-GP, long, with chamfer, ALNOVA
| d | F | l | l | l | d | d | fz | |
| 1 | 175587 | 1 | 2 | 4 | 3 | 2 | ||
| mm | mm | mm | mm | mm | mm | mm | mm/tooth | |
| 3,00 | | 0�13 | 57 | 8 | 12 | 2�8 | 6 | 0�010 - 0�015 |
| 4,00 | | 0�18 | 57 | 11 | 15 | 3�8 | 6 | 0�014 - 0�020 |
| 5,00 | | 0�20 | 57 | 13 | 17 | 4�8 | 6 | 0�018 - 0�024 |
| 6,00 | | 0�20 | 57 | 13 | 21 | 5�5 | 6 | 0�020 - 0�028 |
| 7,00 | | 0�20 | 63 | 19 | 27 | 6�5 | 8 | 0�020 - 0�028 |
| 8,00 | | 0�20 | 63 | 19 | 27 | 7�5 | 8 | 0�030 - 0�038 |
| 9,00 | | 0�30 | 72 | 22 | 32 | 8�5 | 10 | 0�030 - 0�038 |
| 10,00 | | 0�30 | 72 | 22 | 32 | 9�5 | 10 | 0�040 - 0�050 |
| 11,00 | | 0�30 | 83 | 26 | 38 | 10�5 | 12 | 175587 PRECITOOL-GP, long, with chamfer, ALNOVA 0�040 - 0�050 |
| 12,00 | | 0�30 | 83 | 26 | 38 | 11�5 | 12 | 0�045 - 0�055 |
| 16,00 | | 0�40 | 92 | 32 | 44 | 15�5 | 16 | Contents 175587 Type 0�070 - 0�080 |
| 20,00 | | 0�50 | 104 | 38 | 54 | 19�5 | 20 | 6 | 8 | 10 | 12 mm SET 0�070 - 0�090 |
