Roughing cutter HSS-Co

P	M	K	S	DIN	Type	Teeth
N/mm2	N/mm2	HB	N/mm2	844	NR	4-5		30°
							Twist

167401 coated Centre cut

	<1000	< 850	< 240 Titanium <1200
167501					UNI
		vc = m/min.		1835 B

167401	12-40	18-25	20-30	5-15	shank	long		HSS / HSSE End Mill
167501	25-65	35-45	35-55	10-25			16

167401 PRECITOOL, HSS-Co, long, with chamfer

d (k12) d (h6)

167501 PRECITOOL, HSS-Co, long, with chamfer, TiAlN 45° 1 2

	d			l	l	d		fz
	1	167401	167501	1	2	2	Z
	mm			mm	mm	mm		mm/tooth
	6,00			57	13	6	4	167401 0�006 - 0�013
	8,00			69	19	10	4	0�010 - 0�019
10,00				72	22	10	4	0�013 - 0�025
12,00				83	26	12	4	0�016 - 0�030
14,00				83	26	12	4	0�016 - 0�030
16,00				92	32	16	4	d (h6) d k12) 0�020 - 0�038
18,00				92	32	16	4	2 1 45° 0�020 - 0�038
20,00				104	38	20	4	0�023 - 0�045
22,00				104	38	20	5	0�023 - 0�045
25,00				121	45	25	5	0�023 - 0�045
								167501
	Roughing cutter HSS-Co

	P	M	K	S	N	DIN	Type	Teeth
Cat. no.						HSS-Co
	N/mm2	N/mm2	HB	N/mm2	N/mm2	844	NR	30° 4-6
167901								Twist
						coated		Centre cut
	<1000	< 850	< 240 Titanium <1200

167906		Alu < 600 Brass < 600		UNI
	vc = m/min.		1835 B

167901	10-35	15-25	20-30	5-15			shank	overlong
167906	20-60	30-40	35-50	10-25	100-210	75-100

167901 PRECITOOL, HSS-Co, extra long, with chamfer

167906 PRECITOOL, HSS-Co, extra long, with chamfer, TiAlN

	d			l	l	d			fz
	1	167901	167906	1	2	2	Z
	mm			mm	mm	mm		mm/tooth
10,00				95	45	10	4	0�013 - 0�021		45°	d (k12)	d (h6)

1 2

12,00			110	53	12	4	0�016 - 0�026
14,00			110	53	12	4	0�016 - 0�026
16,00			123	63	16	4	0�020 - 0�032
18,00			123	63	16	4	0�020 - 0�032		167901
20,00			141	75	20	4	0�023 - 0�038
22,00			141	75	20	5	0�023 - 0�038
25,00			166	90	25	5	0�023 - 0�038
30,00			166	90	25	5	0�023 - 0�038	45° d (k12)	d (h6)
32,00			186	106	32	6	0�023 - 0�038	1	2

167906
