Roughing cutter HSS-Co
| P M | K | S | Teeth Type DIN | ||||
| N/mm2 N/mm2 | HB | N/mm2 | 30° 4-5 HR 327 | ||||
| Twist | |||||||
| 166206 | <1000 < 850 | < 240 Titanium <1200 | Centre cut coated | ||||
| vc = m/min. | UNI | ||||||
| 166206 | 25-65 35-45 | 35-55 | 10-25 | 6535 HB | |||
| HSS / HSSE End Mill | short shank | ||||||
| 16 | |||||||
| 166206 PRECITOOL, HSS-Co, short, with chamfer, TiAlN | |||||||
| d | l | l | d | fz | |||
| 1 | 166206 | 1 | 2 | 2 | Z | ||
| mm | mm | mm | mm | mm/tooth | |||
| 6,00 | | 52 | 8 | 6 | 4 | 0�006 - 0�011 | |
| 8,00 | | 61 | 11 | 10 | 4 | 0�010 - 0�016 | |
| 10,00 | | 63 | 13 | 10 | 4 | 0�013 - 0�021 | |
| 12,00 | 73 | 16 | 12 | 4 | d (h6) d (k12) 0�016 - 0�026 | ||
| | 2 1 45° | ||||||
| 14,00 | | 73 | 16 | 12 | 4 | 0�016 - 0�026 | |
| 16,00 | | 79 | 19 | 16 | 4 | 0�020 - 0�032 | |
| 18,00 | | 79 | 19 | 16 | 4 | 0�020 - 0�032 | |
| 20,00 | | 88 | 22 | 20 | 4 | 0�023 - 0�038 | |
| 25,00 | | 102 | 26 | 25 | 5 | 0�023 - 0�038 | |
| 30,00 | | 102 | 26 | 25 | 5 | 0�023 - 0�038 |
Roughing cutter HSS-Co
| P | M | K | S | DIN | Type | Teeth | |||
| Cat. no. | HSS-Co | ||||||||
| N/mm2 | N/mm2 | HB | N/mm2 | 844 | HR | 30° 4-5 | |||
| 166251 | Twist | ||||||||
| coated | Centre cut | ||||||||
| <1000 | < 850 | < 240 Titanium <1200 | |||||||
| 166256 | UNI | ||||||||
| vc = m/min. | 1835 B | ||||||||
| 166251 | 12-40 | 18-25 | 20-30 | 5-15 | shank | long | |||
| 166256 | 25-65 | 35-45 | 35-55 | 10-25 |
166251 PRECITOOL, HSS-Co, long, with chamfer
166256 PRECITOOL, HSS-Co, long, with chamfer, TiAlN
d (k12) d (h6)
45° 1 2
| d | l | l | d | fz | ||||
| 1 | 166251 | 166256 | 1 | 2 | 2 | Z | ||
| mm | mm | mm | mm | mm/tooth | ||||
| 6,00 | | | 57 | 13 | 6 | 4 | 0�006 - 0�013 | |
| 8,00 | | | 69 | 19 | 10 | 4 | 166251 0�010 - 0�019 | |
| 10,00 | | | 72 | 22 | 10 | 4 | 0�013 - 0�025 | |
| 12,00 | | | 83 | 25 | 12 | 4 | 0�016 - 0�030 | |
| 14,00 | | | 83 | 26 | 12 | 4 | 0�016 - 0�030 | |
| 16,00 | | | 92 | 32 | 16 | 4 | 0�020 - 0�038 | |
| 18,00 | | | 92 | 32 | 16 | 4 | 0�020 - 0�038 | |
| 20,00 | | | 104 | 38 | 20 | 4 | d (h6) d (k12) 0�023 - 0�045 | |
| 22,00 | | | 104 | 38 | 20 | 5 | 2 1 45° 0�023 - 0�045 | |
| 25,00 | | | 121 | 45 | 25 | 5 | 0�023 - 0�045 | |
| 30,00 | | | 121 | 45 | 25 | 5 | 0�023 - 0�045 | |
| 166256 | ||||||||
| Roughing cutter HSS-Co |
| P | M | K | S | N | DIN | Type | Teeth | ||
| Cat. no. | HSS-Co | ||||||||
| N/mm2 | N/mm2 | HB | N/mm2 | N/mm2 | 844 | HR | 30° 4-5 | ||
| 166486 | <1000 | < 850 | < 240 Titanium <1200 Alu < 600 Brass < 600 | Twist | |||||
| coated | Centre cut | ||||||||
| vc = m/min. | UNI | ||||||||
| 166486 | 20-60 | 30-40 | 35-50 | 10-25 | 100-210 75-100 | 1835 B |
shank overlong
166486 PRECITOOL, HSS-Co, extra long, with chamfer, TiAlN
| d1 mm | 166486 | l1 mm | l2 mm | d2 mm | Z | fz mm/tooth | |||
| 6,00 | | 68 | 24 | 6 | 4 | 0�006 - 0�011 | |||
| 8,00 | | 88 | 38 | 10 | 4 | 0�010 - 0�016 | ° | d1(js14) | d2(h6) |
| 10,00 | | 95 | 45 | 10 | 4 | 0�013 - 0�021 | 45 | ||
| 12,00 | | 110 | 53 | 12 | 4 | 0�016 - 0�026 | |||
| 16,00 | | 123 | 63 | 16 | 4 | 0�020 - 0�032 | |||
| 20,00 | | 141 | 75 | 20 | 4 | 0�023 - 0�038 | |||
| 25,00 | | 166 | 90 | 25 | 5 | 0�023 - 0�038 |
