Tap extractor

For removing of broken taps. Speed 1,500-3,500 rpm. (dry). A firm clamping of the workpiece	Factory	Teeth
is precondition to avoid displacements during the high-speed operation. In case of diagonally	standard	3	6535 HA

coated shank broken taps centring needs to be made by repeated approach. Remove chips regularly.

d (h10) 13 1

Grind diagonally	Reach the centring	Drilling out	Clean the bore and
broken taps flat for good	through repeated approach	with even feed. Repeated	remove the remains with
centring	with a boring tool	chip removal	a pointed object

139815 PRECITOOL, VHM, TiN, 3 cutting edges

			d	l	l	d				d	l	l	d
	d	139815	1	1	2	2		d	139815	1	1	2	2
	1		mm	mm	mm	mm		1		mm	mm	mm	mm
	M3		2�5	50	12	6		M10		8�5	70	25	10
	M4		3�3	50	15	6		M12		10�2	75	30	12
	M5		4�2	50	15	6		M14		12�0	75	30	12
	M6		5�0	50	15	6		M16		14�0	100	40	14
	M8		6�8	60	20	8		M20		17�5	100	50	18
	Thread repair kit							Thread repair assortment
	HELICOIL®plus							HELICOIL®plus
Design:						M	Design:						M
- metric ISO thread							- metric ISO thread
- stainless steel A2						Metric	- stainless steel A2						Metric
						thread							thread
Content:							Content:
- HELICOIL®plus thread inserts							- HELICOIL®plus thread inserts of different
	in three lengths							diameters and lengths
- twist drill up to M12							- twist drill
- HELICOIL®plus hand tap							- HELICOIL®plus hand tap made of HSS
	made of HSS						- HELICOIL®plus installation mandrel
- HELICOIL®plus spindle insert							- chip breaker

- tang breaker up to M12

139831 BÖLLHOFF

d × P		P	Quantity
	139831
mm		mm	of inserts
M2		0�40 20 each M2 × 2 \| M2 × 3 \| M2 × 4
M2,5		0�45 20 each M2�5 × 2�5 \| M2�5 × 3�75 \| M2�5 × 5
M3		0�50 20 each M3 × 3 \| M3 × 4�5 \| M3 × 6
M4		0�70 20 each M4 × 4 \| M4 × 6 \| M4 × 8
M5		0�80 20 each M5 × 5 \| M5 × 7�5 \| M5 × 10
M6		1�00 20 each M6 × 6 \| M6 × 9 \| M6 × 12
M8		1�25 10 each M8 × 8 \| M8 × 12 \| M8 × 16
M8×1		1�00 10 each M8 × 1 × 8 \| M8 × 1 × 12 \| M8 × 1 × 16
M10		1�50 10 each M10 × 10 \| M10 × 15 \| M10 × 20
M10×1		1�00 10 each M10 × 1 × 10 \| M10 × 1 × 15 \| M10 × 1 × 20	139832 BÖLLHOFF
M12		1�75 10 each M12 × 12 \| M12 × 18 \| M12 × 24
M12×1,5		1�50 10 each M12 × 1�5 × 12 \| M12 × 1�5 × 18 \| M12 × 1�5 × 24	Parts	139832	Contents
M14		2�00 10 each M14 × 14 \| M14 × 21 \| M14 × 28
M14×1,5		1�50 10 each M14 × 1�5 × 14 \| M14 × 1�5 × 21 \| M14 × 1�5 × 28	320		M2�5-M6
M16		2�00 10 each M16 × 16 \| M16 × 24 \| M16 × 32	260		M4�0-M10
M16×1,5		1�50 10 each M16 × 1�5 × 16 \| M16 × 1�5 × 24 \| M16 × 1�5 × 32	230		M5�0-M12
