Milling cutter HRC

	H	M			Metric DIN	Teeth
	HRC				13	3
		Metric
138960	≤63	thread		coated
vc = m/min.				H
138960	30-60	6535 HA
			left hand
		shank	cutting
Design:		Use:

- three-fluted thread milling cutter for female threads	- for tempered and hardened	13
- 2 × D	steels 54-63 HRC
- TiAIN coated	- high dimensional accuracy and
- shank design HA	cylindricity of the thread
- left-hand cutting with left spiral	- low radial cutting pressure

138960 JBO, VHM, GFT-H, metric, 2 × D, TiAlN

Type	138960	d1	P mm	l1 mm	l2 mm	l4 mm	d2 mm	Z mm/	fz tooth
0012		M2	0�40	54	1�20	4�4	6	3 0�005	- 0�015
0018		M2�5	0�45	54	1�35	5�5	6	3 0�005	- 0�025
0020		M3	0�50	54	1�50	6�6	6	3 0�005	- 0�025
0022		M3�5	0�60	54	1�80	7�7	6	3 0�005	- 0�025
0024		M4	0�70	54	2�10	8�8	6	3 0�005	- 0�025
0026		M5	0�80	54	2�40	11�0	6	3 0�005	- 0�025
0028		M6	1�00	54	3�00	13�2	6	3 0�005	- 0�025
0030		M8	1�25	58	3�75	17�5	6	3 0�005	- 0�025

Milling cutter Universal

H M Metric Teeth

Cat. no. VHM 60° DIN 2 × D

HRC		13	4-5
	Metric

	138964	≤63		coated thread
	vc = m/min.			H
	138964	30-60		6535 HA
				shank
Design:
- thread milling cutter for female threads			Use:
- 2 × D			Specialised variant of the thread-milling cutter
- TiAIN coated			for the production of internal threads in cured
- shank design HA			or hardened steels of HRC 54-63.
138964 JBO, VHM, GFH, metric, 2 × D, TiAlN

			P	l	l	d		fz
Type	138964	d		1	2	2	Z
		1	mm	mm	mm	mm		mm/tooth
0024		M4	0�70	48	8�7	6	4	0�005 - 0�015
0026		M5	0�80	54	11�6	6	4	0�005 - 0�025
0028		M6	1�00	64	13�5	8	4	0�005 - 0�025
0030		M8	1�25	64	18�1	8	5	0�005 - 0�025
0032		M10	1�50	80	21�7	12	5	0�005 - 0�025
0034		M12	1�75	80	27�1	12	5	0�005 - 0�025
Thread milling cutter with internal cooling

K N M Metric DIN Teeth

Cat. no. VHM 60° 1.5 × D

HB	N/mm2		13	2
		Metric

138980		thread	coated
	≤ 300 Alu alloy ≤600 Copper ≤ 700

138982					K	N
		2 × D		ICS
	vc = m/min.		6535 HA
138980			shank

	100-350 150-300 100-200
138982
Design:	Use:
- thread milling cutter for female threads	- tool for the combined production of
- 1.5 × D / 2 × D	internal threads with countersink
- 45° chamfer	- maximum productivity by reducing non-
- TiAIN coated	productive time, because no tool change
- shank design HA	- specifically for machining of non-ferrous
- right hand spiral flutes	metals and grey cast iron
138980 JBO, VHM, BGF, metric, 1.5 × D, TiAlN	138982 JBO, VHM, BGF, metric, 2 × D, TiAlN

			P	d	l	l	l	l	d	d	fz			P	d	l	l	l	l	d	fz d
Type	138980	d		5	1	2	3	5	k	2	Type	138982	d		5	1	2	3	5	k	2
		1	mm	mm	mm	mm	mm	mm	mm	mm Z	mm/tooth		1	mm	mm	mm	mm	mm	mm	mm	mm/tooth mm Z
0024		M4	0�70 4�2		48 6�85 36 7�4 3�30					6 2 0�030 - 0�070	0024		M4	0�70 4�2		48 8�95 36 9�5 3�30					6 2 0�030 - 0�070
0026		M5	0�80 5�3		54 8�70 36 9�4 4�20					6 2 0�030 - 0�070	0026		M5	0�80 5�3		54 11�10 36 11�8 4�20					6 2 0�030 - 0�070
0028		M6	1�00 6�3		62 10�85 36 11�6 5�00					8 2 0�030 - 0�070	0028		M6	1�00 6�3		62 13�85 36 14�6 5�00					8 2 0�030 - 0�070
0029		M7	1�00 7�4		74 12�00 40 15�7 6�00 10 2 0�030 - 0�070						0029		M7	1�00 7�4		74 16�00 40 19�7 6�00 10 2 0�030 - 0�070
0030		M8	1�25 8�4		74 13�65 40 14�6 6�75 10 2 0�040 - 0�150						0030		M8	1�25 8�4		74 18�65 40 19�6 6�75 10 2 0�040 - 0�150
0032		M10 1�50 10�5			80 17�95 45 19�2 8�50 12 2 0�040 - 0�150						0032		M10 1�50 10�5			80 22�45 45 23�7 8�50 12 2 0�040 - 0�150
0033		M12 1�75 12�6			90 20�75 45 22�2 10�25 14 2 0�040 - 0�150						0033		M12 1�75 12�6			90 26�00 45 27�4 10�25 14 2 0�040 - 0�150
0034		M14 2�00 14�7 102 23�55 48 25�2 12�00 16 2 0�040 - 0�150									0034		M14 2�00 14�7 102 31�55 48 33�2 12�00 16 2 0�040 - 0�150
0035		M16 2�00 16�8 102 25�90 48 27�6 14�00 18 2 0�040 - 0�150									0035		M16 2�00 16�8 102 35�90 48 37�6 14�00 18 2 0�040 - 0�150
