Machine tap set Steel
Design:
M
Chamfer form B Metric
- set in plastic case DIN DIN 60° DIN
HSS-Co 371
Metric 376 13


Tap Drills
- compiled of machine taps , type ST/OX,
L

thread 3,5-5 threads
132310/132410 and twist drills, type N,
CBN ground, 100020
6H
Through hole
P
13
137940 ECOLINE, HSS-Co, with core hole drill, in plastic case
for metric threads 137940 Contents
Machine tap 132310 M3-M10
M3-M12  Machine tap 132410 M12
Twist drill 100020 x 2.5 | 3.3 | 4.2 | 5.0 | 6. | 8.5 | 10.2 mm


Machine tap set Steel
Design:
M
Chamfer form C Metric
- set in plastic case DIN DIN 60°
HSS-Co 371
- compiled from machine taps 133050/133150 and twist drills 100020
Metric
thread
376 40°Twist
L

2-3 threads

DIN
13 6H
Blind hole
2×D P

137950 ECOLINE, HSS-Co, RSP40, with core hole drill, in plastic case
for metric threads 137950 Contents
Machine tap 133050 M3-M10
M3-M12  Machine tap 133150 M12
Twist drill 100020 x 2.5 | 3.3 | 4.2 | 5.0 | 6. | 8.5 | 10.2 mm


Machine tap set Inox
Design:
M
Chamfer form B Metric
- set in plastic case DIN DIN 60° DIN
HSS-Co 371
- compiled from machine taps 135010/135110 and twist drills 100420
Metric
thread
376 L

3,5-5 threads
13

6H
Through hole
M

137980 ECOLINE, HSS-Co, with core hole drill, in plastic case
for metric threads 137980 Contents
Machine tap 135010 M3-M10
M3-M12  Machine tap 135110 M12
Twist drill 100420 x 2.5 | 3.3 | 4.2 | 5.0 | 6. | 8.5 | 10.2 mm


Machine tap set Inox
Design:
M
Chamfer form C Metric
- set in plastic case DIN DIN 60°
Metric
HSS-Co 371 376
- compiled from machine taps 135410/135510 and twist drills 100420
L

thread 40°Twist 2-3 threads

DIN
13 6H
Blind hole
2×D M

137990 ECOLINE, HSS-Co, RSP40, with core hole drill, in plastic case
for metric threads 137990 Contents
Machine tap 135410 M3-M10
M3-M12  Machine tap 135510 M12
Twist drill 100420 x 2.5 | 3.3 | 4.2 | 5.0 | 6. | 8.5 | 10.2 mm


www.precitool.de 13/197
