Machine tap Alu

	N	M	DIN	DIN	Metric Chamfer form B
Cat. no.			HSS-Co	376	60°
	N/mm2		371
		Metric
		thread		from M12	L
137613 Alu < 600			coated		3,5-5 threads
vc = m/min.		DIN	N
137613	15-35		6H
		13
			Through hole
13
137613 ECOLINE, HSS-Co, TiB2

d		P	l	l	l	d	a	l	Core x
1	137613		1	2	4	2		3
mm		mm	mm	mm	mm	mm	mm	mm	mm
M3		0�50	56	9	18	3�5	2�7	6	2�50
M4		0�70	63	12	21	4�5	3�4	6	3�30
M5		0�80	70	13	25	6�0	4�9	8	4�20
M6		1�00	80	15	30	6�0	4�9	8	5�00
M8		1�25	90	18	35	8�0	6�2	9	6�80
M10		1�50	100	20	39	10�0	8�0	11	8�50
M12		1�75	110	23	—	9�0	7�0	10	10�20
M14		2�00	110	25	—	11�0	9�0	12	12�00
M16		2�00	110	25	—	12�0	9�0	12	14�00
M20		2�50	140	25	—	16�0	12�0	15	17�50
Machine tap Alu

N Design: M DIN Chamfer form C

Cat. no. - blank, with 2 cutting edges Teeth DIN

N/mm2 HSS-Co 376

- chamfer form C, 2-3 thread Metric 2-3 371

137708 Alu < 600 Plastics					thread			from M12	45° Twist	L
										2-3 threads
	vc = m/min.			Dimensions:	Metric	DIN			N
					60°		6H	3 × D
137708		18-22	18-22	≤ M6 = solid point		13

Blind hole

137708 PRECITOOL, HSS-Co, blank EE TT

XX EXXPERPPP RP ing

d		P	l	l	l	d	a	l		Core x	*EXEXEEXEE* *chippipii ppp*
1	137708		1	2	4	2		3	Z		s *ng-g-ch*
mm		mm	mm	mm	mm	mm	mm	mm		mm	*loll n* *rial*
											*foff rr lo* te
M3		0�50	56	5	18	3�5	2�7	6	2	2�50	ma fo
M4		0�70	63	7	21	4�5	3�4	6	2	3�30
M5		0�80	70	8	25	6�0	4�9	8	2	4�20
M6		1�00	80	10	30	6�0	4�9	8	2	5�00
M8		1�25	90	13	35	8�0	6�2	9	2	6�80
M10		1�50	100	15	39	10�0	8�0	11	2	8�50
M12		1�75	110	18	—	9�0	7�0	10	2	10�20
M14		2�00	110	20	—	11�0	9�0	12	2	12�00
M16		2�00	110	20	—	12�0	9�0	12	2	14�00
M18		2�50	125	25	—	14�0	11�0	14	3	15�50
M20		2�50	140	25	—	16�0	12�0	15	3	17�50
Machine tap Alu
		N				Design:					Metric DIN M

Plastics HSS-E DIN Chamfer form C

Cat. no. - for blind hole thread 60°

N/mm2	N/mm2			V3	371	376
		- chamfer form C, 2-3 thread	Metric

137711 Copper <600 Alu < 600 Thermoplastics			thread	from M12	45°Twist	L
		- high-speed steel with vanadium content				2-3 threads
	vc = m/min.		DIN		N

137711 15-26 18-32 18-32 Use: 6HX 3 × D

13 Especially for aluminium. Blind hole

137711 PRECITOOL, HSSE-V3, RSP45

d		P	l	l	l	d	a	l	Core x
1	137711		1	2	4	2		3
mm		mm	mm	mm	mm	mm	mm	mm	mm
M2		0�40	45	8	—	2�8	2�1	5	1�60
M2,5		0�45	50	9	—	2�8	2�1	5	2�05
M3		0�50	56	5	18	3�5	2�7	6	2�50
M3,5		0�60	56	6	20	4�0	3�0	6	2�90
M4		0�70	63	7	21	4�5	3�4	6	3�30
M5		0�80	70	8	25	6�0	4�9	8	4�20
M6		1�00	80	10	30	6�0	4�9	8	5�00
M8		1�25	90	13	35	8�0	6�2	9	6�80
