Tap Drills Machine tap Cast Cat. no. KHB137510<300 G Whitworth HSS-Copipe thread coated DIN Chamfer form C G. Whitworthpipe thread 55°5156L2-3 threadsDINISO228 vc = m/min. 137510 15-20 2×D K Through hole Blind hole 137510 ECOLINE, HSS-Co, TiCN 13 d1 - P 137510 d1mm l1 l2 d2 a l3 Core mmmmmmmmmmmm 1/8-28   9.728 90 20 7  5.5 8  8.80 1/4-19  13.157 100 21 11  9.0 12 11.80 d1 3/8-19  16.662 100 21 12  9.0 12 15.25 1/2-14  20.955 125 24 16 12.0 15 19.00 l2 l3 5/8-14  22.911 125 24 18 14.5 17 21.00 3/4-14  26.441 140 26 20 16.0 19 24.50 1-11  33.249 140 28 25 20.0 23 30.75 Machine tap Titanium Cat. no. SN/mm2 NN/mm2137802Titanium <1400Ceramics M HSS- DIN DIN Chamfer form B Metric 60° DINMetricthreadCo PM371376Lfrom M123,5-5 threads13 vc = m/min. 137802 5-8 5-8 6H S Through hole Design: Use: - for through-hole threads Especially for titanium materials. - chamfer form B, 3.5-5 thread - made of powder metallurgic high performance steel - vaporised 137802 HighQ, HSS-Co PM, vaporised d1mm 137802 Pmm l1 l2 l4mmmmmmd2mm amm l3 Core mmmm M3  0.50 56 11 18  3.5  2.7 6  2.50 M4  0.70 63 13 21  4.5  3.4 6  3.30 M5  0.80 70 16 25  6.0  4.9 8  4.20 M6  1.00 80 19 30  6.0  4.9 8  5.00 M8  1.25 90 22 35  8.0  6.2 9  6.80 M10  1.50 100 24 39 10.0  8.0 11  8.50 M12  1.75 110 28 —  9.0  7.0 10 10.20 M16  2.00 110 32 — 12.0  9.0 12 14.00 M20  2.50 140 34 — 16.0 12.0 15 17.50 Machine tap Titanium Cat. no. SN/mm2 NN/mm2137812Titanium <1400Ceramics M HSS- DIN DIN Chamfer form C Metric60°MetricthreadCo PM371376from M1215°TwistL2-3 threads vc = m/min.1378123-63-6 DIN13 6H 1.5 × D S Blind hole Design: Use: - for blind hole thread Especially for titanium materials. - chamfer form C, 2-3 thread - made of powder metallurgic high performance steel - vaporised 137812 HighQ, HSS-Co PM, RSP15, vaporised d1mm 137812 Pmm l1 l2 l4mmmmmmd2mm amm l3 Core mmmm M3  0.50 56 11 18  3.5  2.7 6  2.50 M4  0.70 63 13 21  4.5  3.4 6  3.30 M5  0.80 70 16 25  6.0  4.9 8  4.20 M6  1.00 80 19 30  6.0  4.9 8  5.00 M8  1.25 90 22 35  8.0  6.2 9  6.80 M10  1.50 100 24 39 10.0  8.0 11  8.50 M12  1.75 110 28 —  9.0  7.0 10 10.20 M16  2.00 110 32 — 12.0  9.0 12 14.00 M20  2.50 140 34 — 16.0 12.0 15 17.50 www.precitool.de 13/195
