Threading tool set HSS
| Design: | M | DIN | Metric | ||
| Taps and tap wrenches, dies and die stocks | DIN | 60° | DIN |
HSS EN 6H
of HSS supplied in a metal case. Metric 352 22568 13
thread Delivered in case 13
131400 ECOLINE, HSS, metric,
| for metric threads | 131400 | Contents | |||||||||||||||
| M3-M12 | | 1 set each hand taps DIN 352 (three-piece) and 1 die each DIN 22568 M3 | M4 | M5 | M6 | M8 | M10 | M12 1 die holder DIN 225 each 2035 | 2037 | 2539 | 30311 | 38314 1 adjustabletap wrench DIN 1814 each size 1 and 2 thread gauge screw driver 4�5 mm | |||||
| M3-M20 | | 1 set each hand taps DIN 352 (three-piece) plus 1 die each M3 | M4 | M5 | M6 | M8 | M10 | M12 | M14 | M16 | M18 | M20 1 piece each die holder DIN 225 2035 | 2037 | 2539 | 30311 | 38314 | 45318 1 adjustable tap wrench DIN 1814 each size 1 and 3 thread gauge screw driver 4�5 mm |
Combi tap with 1/4" bit drive
| P | M | DIN | P Chamfer form B | |
| Cat. no. | HSS | |||
| N/mm2 | 352 | |||
| Metric | ||||
| L | ||||
| 131900 | < 850 | thread | 3,5-5 threads |
Use: Tap drilling,, threading and deburring in one operation. For use on power drills with reversing, cordless drills for field work, repair of damaged threads. Important: The tool needs to be able to float self-centring. Not fit for materials with nominal
thread above x (M6 = 6 mm material thickness).
131900 PRECITOOL, HSS, metric
| size | 131900 | P mm | d1 mm | l1 mm |
| M3 | | 0�50 | 2�50 | 36 |
| M4 | | 0�70 | 3�30 | 39 |
| M5 | | 0�80 | 4�20 | 41 |
| M6 | | 1�00 | 5�00 | 41 |
| M8 | | 1�25 | 6�80 | 50 |
| M10 | | 1�50 | 8�50 | 59 |
Combination tap set with 1/4" bit drive
Contents: M Chamfer form B
- 1 bit each M3-M10 DIN HSS 352 - plus adapter Metric thread L
3,5-5 threads
Delivery: In plastic case
131906 PRECITOOL, HSS, metric
size 131906 M3-M10
