Coolants / Lubricants / Compressed Air 165 103 196 129 251 152 Maintenance unit Design: - automatic ventilation in case of overpressure on the secondary circuit - filter regulator self-relieving, with attached oiler - hand wheel can be locked by pressing it down - body of die-cast zinc Z410 - inlet pressure from from 1.5 to max. 12 bar - spring hood POM - membranes and sealings NBR * Oil dosing at 500 l/min - container polycarbonate * Oil dosing at 1,000 l/min - inlet pressure series 0 from 1.5 to max. 12 bar, series 1 and 2 from1.5 to max. 16 bar *** As soon as the input pressure falls below the min. pressure, the drain valve - temperature range up to max. +60 °C opens automatically. By tightening the drain plug, the semi-automatic drain - manometer connection G 1/4" (series 0 G 1/8") valve opening can be prevented - no internal air consumption - pore width in filter 5 μm - semi-automatic condensate drain*** - for compressed air or neutral gases Thread M50x1,5 - ATEX: II 2GD IIA/IIB/IIC T4 0 °C ≤ Ta ≤ 60 °C 136 Thread M30x1,5 93 Thread M30x1,5 93 80 Series 0 Series 1 Series 2 925830 Multifix, 2-piece Type 925830 Thread Pressure regulation Manometer displayrange barbarManometer mmmax. condensate volumecm³Oiler response limit Oil reservebar/l/mincm³Oil meteringSeries 0220  G 1/8" 0.5 - 10 0 - 16 40 16 6 /   26 35 approx. 5 - 10drops/min*0 0230  G 1/4" 0.5 - 10 0 - 16 50 25 6 /   60 50 approx. 1 - 2drops/min**1 0235  G 1/4" 0.5 - 16 0 - 25 50 25 6 /   60 50 approx. 1 - 2drops/min**1 0240  G 1/2" 0.5 - 10 0 - 16 50 50 6 / 140 125 approx. 1 - 2drops/min**2 0245  G 1/2" 0.5 - 16 0 - 25 50 50 6 / 140 125 approx. 1 - 2drops/min**2 Accessories Multifix 925830 Mounting bracket, galvanised steel Type 925830 Design for series 0300  with ring and control panel nut (M30 × 1.5) 0 + 1 0302  with ring and control panel nut (M50 × 1.5) 2 0304  Mounting bracket kit 0 0306  with two long screws 1 0308  with two long screws 2 0300 0306 Design: Coupling packages for connecting individual 92 components of the respective Multifix series Note: Only identical series and thread sizes can be connected by coupling packages 0320 0322 + 0324 0310 925830 Coupling package 925830 Panel nut Type 925830 for series Type 925830 Design for series 0320  0 0310  M30 × 1.5 0 + 1 0322  1 0312  M50 × 1.5 2 0324  2 92/1284 www.precitool.de
