α° α° High-pressure nozzle LOC-LINE® Flexi Design and use: - loadable up to 70 bar, ideal for machining at high speeds - no locking necessary - up to 72° / 110° swivelling (depending on model) - 360° pivotable - for targeted supply with coolant or air flow to 70 bar ‡ 4.‡1 4m.1mmm ‡ 2‡.2 2m.2mmm ‡ 3.‡0 3m.0mmm D D D D α° α° 31.831m.8mmm L L L L 12.712m.7mmm 11/161"1/h1e6x" hex 11/161"1h/e1x6" hex 32 32 42 42 6.4 6m.4mmm R1/8R" 1o/r8R"1o/r4R" 1/4" R1/8"Ro1r/R8"1/o4r"R1/4" 0.0 0m.0mmm ‡ 1.‡6 1m.6mmm 924001 Compact nozzle, (CD) R 1/8" 924001 Extra angle range, (XW) R 1/8"  mm  mm Nozzle length mm 924001 α, ° Nozzle length mm 924001 α, ° Type Type 1,6/0-CD  72° 1,6/0-XW  110° 1,6/6,4-CD  72° 1,6/6,4-XW  110° 1,6/12,7-CD  72° 1,6/12,7-XW  110° 1,6/31,8-CD  72° 1,6/31,8-XW  110° 2,2/0-CD  72° 2,2/0-XW  110° 2,2/6,4-CD  72° 2,2/6,4-XW  110° 2,2/12,7-CD  72° 2,2/12,7-XW  110° 2,2/31,8-CD  72° 2,2/31,8-XW  110° 3,0/0-CD  72° 3,0/0-XW  110° 3,0/6,4-CD  72° 3,0/6,4-XW  110° 3,0/12,7-CD  72° 3,0/12,7-XW  110° 3,0/31,8-CD  72° 3,0/31,8-XW  110° 4,1/0-CD  70° 4,1/0-XW  102° 4,1/6,4-CD  70° 4,1/6,4-XW  102° 4,1/12,7-CD  70° 4,1/12,7-XW  102° 4,1/31,8-CD  70° 4,1/31,8-XW  102° 924002 Compact nozzle, (CD) R 1/4" 924002 Extra angle range, (XW) R 1/4"  mm  mm Nozzle length mm 924002 α, ° Nozzle length mm 924002 α, ° Type Type 1,6/0-CD  72° 1,6/0-XW  110° 1,6/6,4-CD  72° 1,6/6,4-XW  110° 1,6/12,7-CD  72° 1,6/12,7-XW  110° 1,6/31,8-CD  72° 1,6/31,8-XW  110° 2,2/0-CD  72° 2,2/0-XW  110° 2,2/6,4-CD  72° 2,2/6,4-XW  110° 2,2/12,7-CD  72° 2,2/12,7-XW  110° 2,2/31,8-CD  72° 2,2/31,8-XW  110° 3,0/0-CD  72° 3,0/0-XW  110° 3,0/6,4-CD  72° 3,0/6,4-XW  110° 3,0/12,7-CD  72° 3,0/12,7-XW  110° 3,0/31,8-CD  72° 3,0/31,8-XW  110° 4,1/0-CD  70° 4,1/0-XW  102° 4,1/6,4-CD  70° 4,1/6,4-XW  102° 4,1/12,7-CD  70° 4,1/12,7-XW  102° 4,1/31,8-CD  70° 4,1/31,8-XW  102° 92 924003 Adjustment tool HP nozzle Type 924003 Design 0010  Mounting element 92/1256 www.precitool.de Coolants / Lubricants / Compressed Air
